Mechanical Sand Multimedia Water Filter / Tank , High Filtering Capacity

Mechanical Sand Multimedia Water Filter / Tank , High Filtering Capacity

Quick Detail:

Fibre-reinforced plastic ( FRP ) material is 100% of corrosion resistant, especially for sea water treatment, chemical industry, waste water treatment. While its cost is much lower than other metal like stainless steel, it is also widely used in domestic.

Different kinds of manual and automatic solutions are available and optional, such as manual valve and hydraulic diaphragm valve, multi-valve controller, automatic head.

Specifications:

1) Material: inner shell-Polyethylene (PE),Outer shell-Fiberglass with Epoxy resin
2) Working pressure:0.6Mpa(100psi/6bar) - 1.0MPa(150PSI / 10 bar)

Diameter dimension: 6\" to 120\"( 155 mm to 3000 mm )

Vertical or horizontal are both available.

Custom design is available.

Different color are available:

Specification:

A) Material:

(a). inner shell – Polyethylene (PE) seamless one-piece tank liner

(b). Outer shell – Continuous strands of fiber-glass with high strength epoxy resin

(c). Bottom base – FRP reinforced tripod base

(d). Opening – 4” precision injected model with threaded opening for 21 \", 24\", 30 \", 36\" diameter tanks
(e). Opening – 6 \"Aluminum flange (anti-corrosion coating) opening for 36”, 42” ,48”, 63” diameter tanks

B) Working Pressure:

(a) ?≤0.6MPa(100PSI)

(b) ≤1.0MPa(150PSI)

C) Working Temperature : ≤49°C

D) Maximum Vacuum : 127mmHg(5\"Hg).

E) Maximum Temperature : 40C (104F)

F) Certificates: CE ;NSF ; ISO9001 etc.

G) Media : water

Application:

All feed water and waste water treatment application, included multi-media filter and softener.

Applications:

Specifications:

Competitive Advantage:

JCD WATER is professional manufacturer of water treatment equipments. We provide high quality products with advanced technologies, fast delivery and reasonable cost to meet customers’requirements. Meanwhile we distribute a lot of accessories for convenience of our customers.

JCD WATER covers water treatment equipment manufacturing, system assembling, accessory distributing and supply economic and efficient solutions for water treatment projects.

Within our professional services, we provide you best solutions to assist you win the market, including design, production, maintenance, delivery. Our principle is to make you win, then we win.
