Home > Products > PLC HMI > Communicate With Brand Of PLC Operate Panels Integrated PLC HMI 20 Function Buttons 3.7'' LCD
Communicate With Brand Of PLC Operate Panels Integrated PLC HMI 20 Function Buttons 3.7'' LCD
- T/T L/C D/P D/A
- 7 days
You May Like
-
RS45 Serial Port Support Modbus 3.7 Inch Operation HMI Panels With 26 Buttons Dynamic Text Display
-
Two Communication Ports 3.7 Inch LCD Industrial Operate HMI Panels Connect To ABB PLC
-
Mitsubishi / AB PLC HMI Touch Screens RS232 Backlight STN LCD , Natural Air Cooling
-
RS485 Touch Screen PLC HMI PC Panel With Servo And VFD , HMI Interface
-
3.7\" LCD Touch Screen Human Machine Interface HMI In PLC Serial Port Connect VFD
-
Alarm Function And Text Display Operate HMI Panels With Real Time Clock 3.7\'\' LCD
Product Details
| Brand Name | XINJE | Place of Origin | China | |
| Model Number | OP325-A-S |
Product Description
Certification:CE, ISO9001
Communicate With Brand Of PLC Operate Panels Integrated PLC HMI 20 Function Buttons 3.7\'\' LCD
Quick Detail:
3.7 inch LCD,
power supply DC24V,
OP series?PLC HMI (human machine interface),
20 function buttons,
can communicate with most brand of PLC models.
Description:
3.7 inch LCD, 20 function buttons
Can communicate with most brand of PLC, such as?Omron PLC
Password protection and internal clock
Dynamic and fixed text displaying
Alarm information list, show real-time alarm information
20 buttons can be defined to different functions
The LCD has backlight
STN LCD
External RS485 terminals for Modbus communication
Specifications:
General Specifications
|
Display |
Model |
Blue color LCD |
|
Using life |
Up to 20000 |
|
|
Display area |
192*64 |
|
|
Brightness |
Can be adjusted by Potentiometer |
|
|
Language |
Simplified Chinese/ English/Spanish/German… |
|
|
Character |
Chinese: 16*16 32*3 English:8*16 16*32 |
|
|
Key-press |
20 buttons |
|
|
Memory |
Screen |
64KB Flash ROM |
|
Data |
1KB SRAM |
|
|
Interface |
Download Port |
RS232 |
|
COM Port |
RS232 /RS422 ( or RS232/RS485)
?External RS485 terminal |
Function Specifications
|
Electrical Features |
Input Voltage |
DC24V |
|
Voltage Range |
DC22V~DC26V |
|
|
Current Consumption |
<140mA |
|
|
Allowable Momentary power-cut |
Less than 10ms |
|
|
Voltage Endurance |
AC1000V, less than 20mA for 1 minute |
|
|
Insulated Resistance |
Above 10M,DC500V |
|
|
Environment |
Operation Temperature |
0 to 50 |
|
Storage Temperature |
-20 to 60 |
|
|
Operation Humidity |
10%RH to 90%RH(No condensation) |
|
|
Interference Rejection |
Noise voltage;1500Vp-p, Pulse cycle:1uS , Druation:1 minute |
|
|
Atmosphere |
Free of corrosive gas |
|
|
Structure |
Cooling Method |
Natural air cooling |
|
External Dimension |
172.0*94.0*30.0 |
|
|
Cutout Dimension |
163*85 |
Applications:?
OP series HMI can communicate with most brand of PLC, such as Siemens, Mitsubishi, ABB, Omron, AB and so on. It also can communicate with frequency inverter and other devices.
