Mineral Water Bottle Filling Machine Aseptic 0.5L Liquid Filling Line PLC Controled

Brand Name	Jiayuan		Place of Origin	China
Model Number	CGF24-24-8

Delivery Time:30 days
Certification:CE,SGS

Mineral Water Bottle Filling Machine Aseptic 0.5L Liquid Filling Line PLC Controled

Quick Detail:

1. Product: CGF24-24-8 water filling machine

2. Model:CGF24-24-8

3. Main Material: SS304

4. Production capacity: 8000-10000bph(500ml)

5. Usage: Fill pure/mineral/distilled water and so on

6. Dimension: 2750*2180*2200mm

7. Warranty: 1year free

CGF24-24-8 Drinking water filling machine

Description:

Jiayuan CGF24-24-8 drinking water?filling machine and packaging machinery?is a self-developed new product by our Jiayuan machinery co.,ltd to meet the requirement of multi-usage demands for our customers. The?mineral water?filling?machine is consisted of rinsing-filling-capping all together. It?can fill mineral water, pure water and?distill water etc. Jiayuan CGF24-24-8 drinking water?filling machine adopts the suspension design. It allows the machine to fill different type of the bottles. It is normally used as mineral water filling machine. However, Jiayuan CGF24-24-8 drinking water?filling machine can also be used?for fill PET bottle with fruit juice and tea at normal temperature by?simply add the juice mixing machine part. It can be connected with our others machines to form the?mineral water?filling?production line.

Application:

This machine is designed for bottling non-air drinks, such as pure water, mineral water etc, it
integrates bottle washing, filling and capping into one monobloc unit.

Specifications:

1) Feature

The mineral water filling machine adpots advanced human-machine interface control. High quality international name brand key components Suspension bottle neck catcher structure allows the machine change the bottle type easily. By changing the valves, it also can be used as hot filling machine Spring type rinsing catcher can wash both inside and outside of the bottle High accuracy pressure water?filling mechanism, ensure the height and quatity of the water filling Magnetic powered cap?device ensures tightness and prevents damage of the caps Quiet, rotary cap?unscrambler will not damage caps. Photoelectric sensor?detect missing caps thus eliminating uncapped bottle spillage Built-in safeguard mechanism ensures the safety of operator and machine. High efficient air clean filter system ensures high sanitary requirements Low overall machine noise Self-lubricating system imported from America provides continuous smooth operation

2) Technical parameter

Model	CGF24-24-8
Material	SS304
Pump	Nanfang(China famous brand)
PLC	Mitsubishi
Frequency converter	MITSUBI
Washing head	24pcs
Filling head	24pcs
Capping head	8pcs
Water consumption for bottle	2500kg/h
Total power	6.57kw
Total weight	5500kg

3) Pictures:

Washing head

Filling head

Capping head

Competitive Advantage:

Jiayuan machinery co.,ltd is a professional manufacture of liquid packaging equipment.

1. The company around 110 KM away from Shanghai, has convenient traffic.

2. The company was established in 1999, has rich experience.

3. We are an CE&SGS certified company.

4. We can produce kind of filling&packing machine, such as

Bottled water production line Carbonated soft drinks production line Hot-fill juice and tea production line 5 Gallon bottled water production line Water treatment machine and packing machine

5. Jiayuan machinery co.,ltd can provide turn-key services for customers, from plant layout, equipment manufacturing, production line setup and operators training.
