Home > Products > Seamless Steel Tubes > ASTM A335 P9 P11 P12 P21 Seamless Alloy Steel Tubes with Bevel Ends ISO PED , 25000mm Length

ASTM A335 P9 P11 P12 P21 Seamless Alloy Steel Tubes with Bevel Ends ISO PED , 25000mm Length

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	JIANGSU HUACHENG		Place of Origin	China
Model Number	HC

Product Description

Delivery Time:25~35days
Certification:ISO9001 14001 BV TUV PED DNV etc

ASTM A335 P9 P11 P12 P21 Seamless Alloy Steel Tubes with Bevel Ends ISO PED , 25000mm Length

Quick Detail:

Products:ASTM A335 A335M

Seamless?ferritic?alloy-steel?pipe?for?high-temperature?service
Standard:ASTM A335
Grade:P1, P2, P5, P9, P11, P12, P21, P22, P91, P92
OD. Range:12.7 mm – 114.3 mm

Wall thickness: 0.8 mm-15 mm

Length: Max length 25000mm

Description:

1, Product name?
ASTM A335 alloy steel pipe

2, Standard?
asme SA213,astm a213, asme?SA335, astm a335, A369, A209, A250, G3462, G3467, DIN17175, BS3059-2

?
3, Material
SA213: T2, T5, T9, T11, T12, T22, T91, T92
SA335: P1, P2, P5, P9, P11, P12, P21, P22, P91, P92
DIN17175: 15Mo3, 13CrMo44, 10CrMo910, 12CrMo195
BS3059: 360, 440, 460, 620
JIS G3458: STPA12, STPA20, STPA22, STPA23, STPA24, STPA25, STPA26
JIS G3462: STPA12, STBA13, STBA20, STBA22, STBA23, STBA24, STBA25, STBA26

4, Outside diameter: 12.7 mm~114.3 mm
5, Wall Thickness: 0.8 mm~15 mm
6, Length: 6m-25m, also can be manufactured by customers\' requirements
7, Type: Seamless
8, Type of ends: Plain ends or bevel ends
9, Coating for protection: Can be required according to customers\' requirement

Chemical?properties???(%):

Material	C	Si	Mn	P	S	Mo	Cr
	%	%	%	%	max	%	max
A?335?Grade?P1	0,10?-?0,20	0,10?-?0,50	0,30?-?0,80	0,025	0,025	0,44-0,65
A?335?Grade?P5	max.?0,15	max.?0,50	0,30?-?0,60	0,025	0,025	0,45-0,65	4,00-6,00
A?335?Grade?P11	0,05?-?0,15	0,50?-?1,00	0,30?-?0,60	0,025	0,025	0,44-0,65	1,00-1,50
A?335?Grade?P12	0,05?-?0,15	max.?0,50	0,30?-?0,61	0,025	0,025	0,44-0,65	0,80-1,25
A?335?Grade?P22	0,05?-?0,15	max.?0,50	0,30?-?0,60	0,025	0,025	0,87-1,13	1,90-2,60

?Mechanical?properties:

Material	Tensile?N/mm2	Strength?Min.?N/mm2	Yield?%?min.
A?335?Grade?P1	min.?380	205	30
A?335?Grade?P5	min.?415	205	30
A?335?Grade?P11	min.?415	205	30
