CMS800G Fetal Monitor---CE Apporved

Features of CMS800G Fetal Monitor

Model: CMS 800G Fetal Monitor

CMS 800G Fetal Monitor can provide different configurations according to different user requirements: FHR1 (Ultrasonic Channel 1), FHR2 (Ultrasonic Channel 2), TOCO, FMOV (Fetal Movement Marker). Monitoring results can be recorded by built-in recorder for continuous or intermittent records.

The fetal monitor can be used individually or connected with PC through RJ45 Interface for the purpose of central monitoring.

1. Compact and portable design, can be put on table or wall mounted
2. 8.4" color LCD screen display which can be rotatable up to 60
3. Display of the patient data and curve clearly
4. Can record fetal movement manually
5. High and low fetal heart rate alarm function
6. Continuous 24-hour real-time monitoring
7. Continuous 12-hour patient curve and data storage with playback ability

8. With picture freeze function
9. Chinese and English operation interface selectable
10. Single, Twins Monitoring selectable
11. 9 chip pulse width beam probe
12. Extra-long life, high-resolution built-in thermal printer which can output waveform, text, and other information

13. Built-in RJ45 communication interface, can be connected with central monitoring system

Specification:

Ultrasound probe nominal frequency: 1.0MHz
FHR Range: 65BPM~210BPM; Accuracy: 2%
AC power supply voltage: AC100V~240V; Working Frequency: 50Hz/60Hz
TOCO Range: 0~100%; Resolution: 1%Fetal marking: Manual push button(Operated by pregnant women)
Optional: Twins monitoring ultrasound probe FH
