380V / 240V Paintball Manufacturing Machine With Small Load Difference / 304 SUS
Negotiable
/ Set
1 Set(Min.Order)
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Precise Paintball Making Machine / Encapsulation Machine With Drum Design
-
Largest Paintball Encapsulation Machine / Paintball Maker For Real Man CS Game
-
Humanized Softgel / Capsule Inspection Machine / Inspection Table With 304 SUS
-
Paintball / Softgel Capsule Sorting Machine / Size Sorter 304 SUS For Pharmaceutical
-
Low Energy Consumption Capsule Sorting Machine With 6 Rollers / 300000 Max
-
Pills Capsule Sorting Machinery / Spherical / CylindricaL / oval / 8 Sorting Rollers
Product Details
| Brand Name | KUN YOU | Place of Origin | China | |
| Model Number | S403PB |
Product Description
Certification:CE
380V / 240V Paintball Manufacturing Machine With Small Load Difference / 304 SUS
Quick Detail
|
Die Roll Size |
Ф80X100mm |
Material |
304?SUS |
|
Application |
Paintball?Making/Softgel Making |
Weight |
600kg |
|
Scale |
Small?Scale?Production |
Capacity |
8000pcs/hour |
Product Description
Our company is the first in China to export paintball equipment to North America which is capable of making tournament grade paintball, still the biggest paintball machine maker in China. Compared with the softgel machine, the paintball making machine need better machine accuracy, the drive transmission system is also precisely improved. The ancillaries are also modified correspondingly. The hopper and spreader box adopt level switch, making the level control more precise. Besides, the injection wedge, spreader box and hopper adopt the design of precise PID temperature control . The micro lubrication system largely reduce the consumption of paraffin oil.
Paintball making machine is used for making different color paintballs for game.
S403PB Paintball making machine is an experimental paintball machine designed especially for R&D department of laboratories, pharmaceutical factories in the universities and plant health products and Research Institutes.?
Specification
|
Die?roll?size? |
Ф80X100mm |
|
Die?roll?speed |
0~5rpm |
|
Overall?dimension |
1250×400×2300mm |
|
weight |
600kg |
|
Power?supply |
380V/240V,50/60HZ |
|
Power?of?the?main?motor |
1.1kw |
|
Power?of?the?main?machine |
3kw |
Competitive Advantages
1. Small size, low energy consumption?
2. Easy to operate and clean
3. High precision
4. Small load difference
5. Micro lubrication
6. High quality and intelligence control system, PLC true color touch screen technology adopted by the electronic control system. All electric parts use world brand parts, such as Siemens, Schneider.
7. The hopper can keep medicine temperature steady, more suit to fill suspension into the paintball.
8. Air-cooling system is adopted at the output of paintball, that make paintballs amazing?
9.Professional PID temperature control technology is adopted on the machine, temperature of injector can be adjusted accurately. Improves ratio of finished products of paintball.
