Hydraulic Steel Coil Upender , 1300mm Coil Width 125mmX1 Cylinder

Hydraulic Steel Coil Upender , 1300mm Coil Width φ125mmX1 Cylinder

3T Coil Upender , 1300mm Coil Width φ125mmX1 Cylinder?

Description:

Function:? It is an equipment which is used to carry the coil materials by making the laying coils stand or making the standing coils lay to go on the process of dealing with the coils.

Design: According to the different coil specification, our company can design the related turnover machine to meet customers specific requirements.

Usage: Turnover machine is easy to operated as the seller will equip the whole devices including the complete hydraulic system and the electrical system. The buyer only need to supply the power and the hydraulic oil, then it can work.

Guarantee: all the equipments are passed our company’s test so we can guarantee the quality

Applications:

Specifications:

a. Max Coil width: 1300mm

b. Max Coil diameter:800mm

c. Capacity:3T

d. Rated power: 7.5kw

e. machine weight:about 2.5T

f. the diameter of hydraulic oil cylinder: φ125mmX1

g. pressure of hydraulic system: 0-16Mpa

h. oil pump model: CBT-F325

I. it will take about 20 seconds to turn from one position to another side.

Competitive Advantage:

All our machines can be built-in-order. our company can design the related turnover machine to meet customers specific requirements.

Turnover machine is easy to operated with the good quality and best price.
