Small rolling mill

Small rolling mill for 200 x 2 type rolling mill, the diameter of the roll is 200 mm.

Small rolling mill can be mainly used to roll bar and rod, which adopts three work roller frame with two roller frame. The main equipment for rolling mill is composed of a host list.Rolling mill host column is made up of motor, transmission device and actuators of three basic parts. By way of configuration for rolling mill motor, reducer, gear stand - rolling mill host.

Due to the irreversible steering and speed roll, using low cost High-speed motor. Considering the rolling load is very uneven, in order to balance the motor load, reduce the capacity of motor, between the speed reducer and the motor with the flywheel.Gear stand: its purpose is to transfer torque to the work roll, the design USES three equal diameter cylidrical herringbone gear in a row in a vertical plane, in a sealed enclosure.Coupling: between the reducer and gear stand adopts safe axis.the plum blossom is used in the main coupling shaft coupling

Scope of application: rolling mill can be used in the production of deformed steel bar, flat steel, square steel, Angle steel, channel steel, also other varieties of rolling profile, aluminum, copper, plate, strip steel, scrap steel, such as restructuring.
