Flexibility Revolving Shrink Wrapping Machine Modular 150 packs / min

Flexibility Revolving Shrink Wrapping Machine Modular 150 packs / min

Description

Shrink wrapping machine is an automatic packing equipment which continuously unfold the film roll to cut the film at required length,and deliver the film by vacuum adsorption slope conveyor to the bottom of a group of container,the container continues to forward at the same time the revolving rod puts the film to wrap the container,and the film ends overlap to the film initial position under the container,then the wrapped plastic container is fed into a heating tunnel,finally form the film shrink wrapped product.The machine is composed by container feeding device,the container grouping and arrange device,firm stretching device,film cutting device,film delivering device and shrink film wrapping and shrink tunnel.It can be used to pack different containers,such as:plastic bottles,glass bottles,cans,jars or a plurality of small packaging.Packing capacity can be up to 150 packs per minute.

Application

System Advantage

1. Multi-pitch configuration

2. Modular structure

3. Flexibility

4. Perfect cases

5. Versatile packs

6. Motors directly connected to the drive shafts

7. User-friendly”man-machine interface

8. Easy and low-cost maintenance;

9. Plastic dividing combs

10. Continuous motion pack formation

1. Basic specification description

1.1Capacity:25 packs per minute

1.2Packing:film+tray

1.3 Bottle dividing: ?cylinder type

1.4Bottle shape:

(1)Glass bottle, PET bottle and can etc. Diameter: ?55~110mm

????? (2) Bottle height: H80~320mm(Notice:each bottle diameter and height difference±2mm, otherwise thought as another bottle size)

1.5Pack size

1.6 Machine dimensions:

a. Main machine: 8090mm*1650mm*2600mm(L*W*H)

b. Infeed conveyor? L1500mm,W540mm

1.7 Total power: 47 KW

1.8Control power:24V? DC

1.9Compressed air?? (a)Pressure:0.4~0.8MPa?? (b)Air consumption:100L/MIN

1.10Weight: 6T

1.11Floor load : ∽8 X 7500 N

1.12Horizontal angle : ± 1°

1.13Noise :? ≤ 85 dB

2.Film specifications

2.1.Material:high density polyethylene heat shrink film HDPE, transparent or little bit ivory-white.

2.2. Thickness:0.06~0.08 20% mm ；

2.3. Density:0.928g/cm3 ；

2.4. Anti-static additive: ?10KV;

2.5. Max. film roll diameter: less than 500mm;

2.6. Film core diameter: 76mm

2.7. Transverse shrinkage:? 70~80 %

2.8. Longitudinal shrinkage:? 10~20 %

2.9. Anti-cutting: Longitudinal 28N/mm2 ; Transverse 21N/mm2

2.10. Anti-twisting: Longitudinal 14N/mm2 ; Transverse 14N/mm2

2.11. Max. extensibility: Longitudinal 450% ; Transverse 650%

2.12. Anti-tearing: Longitudinal 350g; Transverse 500g

2.13. Joint temperature: 130~160 o C

3. Structure characters:

3.1 Patent design bottle infeed system: collocation can be for a variety of products, changing bottles and collocation easy to adjust, no need additional change over parts, low-impact bottle separating system, suitable for beer bottle, soft PET bottle etc.

3.2 Advanced configuration, safe and reliable:main drive using import servo controller, servo motor, FESTO pneumatic system, SICK sensor and B&R system, PLC module integrated control etc., ensure machine running low failure and high efficiency.

3.3 Unique film unwinding and film pre-cut device:film unwinding constant tension transmission, servo motor control, and clutch film cutting and a speed position sensor, to control the film length, cancelling the single cylinder control mode.

3.4 High production efficiency:The double film rolls can be used alternately, it takes only one minute to change the film. No film machine stops, continuing linear motion when operating, speed adjustable, variable speed, high production efficiency.

3.5 Fine material and durable:machine frame, driving parts using import aluminum and stainless steel material, life span few times than material made in China, the
