380V H-Beam Production Line Strip Vertical Flame Cutting Machine , 6mm - 200mm Thickness

Brand Name	Sunny		Place of Origin	China
Model Number	NC-4000

Delivery Time:30 work days
Certification:Certification of original

380V H-Beam Production Line Strip Vertical Flame Cutting Machine , 6mm - 200mm Thickness

Kindly Noted:

Customer could choose the Model from NC-2000 to NC-8000. Voltage standard is 380V , 50HZ , 3PH. Other voltage please kindly let us know. Customer should provided us technical parameters,such as the effective cutting width and length,cutting thickness. We could according to customer’s requirement,to decided how many cutting torches customer needs. Track gauge up to 4000mm ,adopt to double driven.

If you are interested in this machine, would you please kindly advise us the information as follow:

1. Main material of the workpiece, it is better to send us the cutting drawings or your product pictures.

2. The effective cutting width and length, Material and cutting thickness.

4. How many cutting torches need ?

5. Other special requirement if you have.

We will offer you the best solutions and quotation upon receipt of your detail requirement.

Description:

NC vertical flame cutting machine is a kind of ?high-precise? cutting device, The lifter the aluminum alloy structure. It is led by screw. guided by straight line bearing,the precision is guaranteed,The vertical guide track adopts heavy rail.The surface has high precision and wear-ability via grinding post processing .The gantry type structure design can ensure the high strength and rigidity. It equipped with Panasonic servo motors and Germany Neugart reducer, it runs steadily and cutting with a high precision.

Applications:

The NC Oxy Cutting Machine mainly used for cutting Mild steel , Stainless , Aluminum ,and also used in H-beam production

Specifications:

Model	NC-2000	NC-2500	NC-3000	NC-3500	NC-4000	NC-4500	NC-500	NC-5500	NC-6000	NC-7000	NC-8000
Track Gauge(mm)	2000	2500	3000	3500	4000	4500	5000	5500	6000	7000	8000
Effective Cutting Width (mm)	Track Gauge-800
Track Length (mm)	10000?? 12000? 14000
Effective Cutting Length (mm)	Track Length-2000
Driving Modes	Single Driven?? Double Driven
Driving Speed(mm/min)	50-6000
Repeat Precision (mm)	±0.5
Cutting Roughness(mm)	Ra12.5
Cutting Precision	±0.5/1000mm
Cutting Thickness(mm)	Flame Cutting:6-200? Plasma Cutting:Determined by the Macthed Power Supply

Draft drawing:

Brand using:

Servo motor is made by Japan Panasonic

Travel reducer is made by Germany NEUGATE

Horizontal Rails is made by Straight line track

Competitive Advantage:

1.The horizontal guide track adopts a straight line track with high precision and smooth running.

2.The machine body is gantry type structure:the crossbeam is treated by whole annealing to eliminate stress

3.The lifter the aluminum alloy structure. It is led by screw. guided by straight line bearing,the precision is guaranteed.

4.The travel reducer adopts Germa
