Home > Products > Outdoor Full Color Led Display > 6944 pixel 2R1G1B P12 full color curved led mobile display electronic DIP 346
6944 pixel 2R1G1B P12 full color curved led mobile display electronic DIP 346
Negotiable
/ Kilogram
1 Kilogram(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
High definition 1R1G1B Indoor Led Video Display Pixel Pitch 10mm For Advertising
-
High Resolution P6 Indoor LED Video Display for Advertising with WIN 98 / 2000 / XP
-
Commercial scrolling Indoor Advertising LED Display Full color 3000K 9500K
-
RGB Indoor advertising LED display billboard 350W 10000 dots/sqm for meeting room , TV
-
Commercial Advertising LED SMD Display Indoor Full Color 32 x 16dots 1/8 scan
-
SMD Indoor high resolution electronic LED video display advertising 220V , 50Hz
Product Details
| Brand Name | LED DISPLAY | Place of Origin | China | |
| Model Number | 4*3m |
Product Description
Certification:CE & ROHS
6944 pixel 2R1G1B P12 full color curved led mobile display electronic DIP 346
Specifications
P12 led electronic board,high brightness,large viewing angle,easy to maintenance,waterproof metal frame,video fucntion
P12 led electronic board information:
| Display and control feature? | Structure feature? | ||
| Specification | Parameter | Specification | Parameter |
| Pixel Pitch | 12 mm | Module size | 192 mm*192 mm |
| Pixel composing | 2R1G1B | Display resolution/module | 16 dots*16 dots |
| Wavelength (R) | 625±5 | Standard cabinet size | 960 mm*960 mm |
| Wavelength (G) | 522±3 | Weight per sqm | 65 Kg/sqm |
| Wavelength (B) | 567±3 | Protection classification | IP65 |
| Wave Angle (H) | 140°(H)/ 60° | Install mode | Wallmount, hung and stand structure |
| LED package | DIP 346 | Cabinet Material | Iron |
| Density per sqm | 6944 pixel | Working power | |
| Display color | 256*256*256 | Specification | Parameter |
| Whiteness brightness | ≥5000 | Working voltage | AC 220v/380v±10% 47~64Hz |
| Brightness level | 128 grade | Max power/sqm | 700W/sqm |
| Changing frame frequency | 60 Hz | Average power/sqm | 400W/sqm |
| Refresh | 400 Hz | Short circuit protection | Yes |
| Driving method | 1/4 Constant Driving | Led Lamp type | Red:Opto Blue:Silan Green:Silan |
| Control mode | synchronous | Working environment | |
| Display port | DVI | Specification | Parameter |
| Display mode | 1024*768 /1024*1024 | Environment | Outdoor |
| Out of control | 1/10,000 ( scattered) | Working temperature | --20~50°C |
| lifetime | 100,000 hours | Working Humidity | 10~90% |
