HDG Q235 1.5" Cuplock Screw Jack Base Bridge Falsework For Aerial Work

Brand Name	EG; EAST GRACE; OEM		Place of Origin	China
Model Number	SJB; SJS

Delivery Time:According to Order Quantity
Certification:BS|EN

Description:

Cuplock scaffold, also known as Cuplok is one of the worlds most widely and successfully used modular scaffolds. Its unique locking action makes it the fastest, safest and most economic system available, also makes it the example of the safe scaffold market of the worlds. Cuplcok was introduced to China in the late 1980\'s and now Chinese can supply quality products all over the world.

One Cuplock Standard node point enables up to 4 components to be fastened at once just with one hammer. The locking device is formed by two cups, a fixed bottom cup that is welded to the standard at pre-located 0.5m intervals, top cup can slide up and down within the restricted range. Locate the blade end of the ledgers into bottom cup, drop down and rotate the top cup to secure the component in place, then tighten with the hammer. How simple the assembly procedure --Provides Vertical Support for Scaffolds;

Applications:

The Screw Jack has an adjustment of approximately 0.45m and is used for both access and support structures to accommodate variations in ground and soffit levels. For support, load bearing capacity of up to 75kN (breaking loading about 140KN) .

SJS –Swivel Screw Jack base, will be used on the slope base ground for supporting.

Specifications:

Code	Specification	Tube Size	Material	Weight
SJB	Screw Jack-HDG 1.5\"	Φ38.1 x 5mmx533mm	Q235	7.7lbs/5.0kg
SJS	Swivel Screw Jack HDG 1.5\"	Φ38.1 x 5mmx533mm	Q235	8.4lbs/3.8kg

Finishing Hot Dip Galvanization (HDG), Electrical Galvanization (EP) is for option;

Competitive Advantage:

Cuplock System Scaffolding combines the speed of frame scaffolding and the flexibility of standard pipe and coupler scaffolds. Ledgers, Diagonals can be fastened on the Standards with one hammer.

Cuplock System scaffolding can provide you fast and reliable scaffolding solutions.

We always pay more attention on the quality, and provide quality &customers’ satisfied products with best price, which can meet their budget and projects.

Our hot-sale product is below:

Ringlock System Scaffolding

Cuplock System Scaffolding

Frame System Scaffolding

Shore Prop

?Formwork Parts

Welding Workshop

Machining Workshop

Drop Forged Workshop

?Casted Workshop

?Packing Workshop

?Packing and Delivery Processing:

Prompt reply and response,for any inquiry,we will reply you within 24hours

Reasonable price

Satisfactory pre-sale service&after-sale services.

color:	According to customers
sample time:	7~10days after receiving your payment
delivery time:	with 20days after receiving your downpayment
payment:	T/T, L/C, D/P

T/T 30% or 50% downpament,,the balance before the shipment

Product:

We have more than 20 years of experience in manufacturing & exporting

System Scaffolding Formwork Parts Hardware Parts Casted Parts Dorp Forged Parts

Company instruction:

We have a reputable, funny, enthusiastic and down-to-earth team with high ability. \"Customer oriented, meet customers\' demands, exceed customers\' expectation\" is our tenet. We will keep innovating and improving products, service and management to sharpen our competence.

All of our products have been strictly controlled by us, and we ensure thoughtful services and competitive prices.
