90 PCB Shield Modular RJ45 Jack 10 / 100Base-Tx PA66 with Metal Shell
- T/T L/C D/P D/A
- 7 days
You May Like
-
1X1 Tab-Down Right Angle Modular Jack RJ45 with 90 Degree Connector 8P8C
-
8 Pin 8 Contact Phone Modular RJ45 Jack Connectors One Port OEM
-
Receptacle AMP Modular RJ45 Jack 8P8C 100Base with Side Entry
-
Cat 6 Magnetic Modular RJ45 Keystone Jack 180 Degree KRJ - 181NL
-
Two Port Lan Modular RJ45 Jack , Right Angle UTP Joiner With Transformer
-
2 Port RJ45 Modular Jack With Magnetics , Female Right Angle Connector 10P8C
Product Details
| Brand Name | DGKYD | Place of Origin | China | |
| Model Number | KRJ-13PBNL |
Product Description
Certification:GP,ROHS,SGS,ISO9001
?
90° PCB Shield Modular RJ45 Jack 10 / 100Base-Tx PA66 with Metal Shell
?
?
Quick Detail:
?
1.Single Port
2.Type: Modular RJ45 connector
3.Contact Material: gold?pin phosphor bronze
4.TAB direction: Down
6.LEDS:NO
6.Length:?21.3mm
?
?
Descriptions:
?
＊?Number?of?positions:8
＊?Number?of?contacts?loaded:8
＊?Shield:YES
＊?Rohs?compliant(GP)
＊?Length:21.3mm(0.85inch)
＊?LED:NO
＊?EMI?fingers:NO
＊?Usage:LU1S041-LF/KRJ-13PBNL
＊?10/100Base-Tx?RJ45?single?port?1X1?Vertical?w/o?LED?with?side?entry
＊?Single?port?1X1?Tab-Down?RJ45?with?internal?magnetics?????????????
＊?Internal?magnetics?are?100%?electrically?tested?for?HI-POT?and?functionality
＊?Suitable?for?CAT5&6?fast?Ethernet?Cable?or?better?UTP
＊?350uHminimum?OCL?with?8mA?bias?current
＊?High?performance?for?maximum?EMI?suppression
＊?Minimum?1500Vrms?isolation?per?IEEE?802.3?requirement
＊??ROHS-6?peak?wave?solder?temperature?rating?260℃
＊?Operating?temperarure?range?:0℃?to?+70℃
＊?Storage?temperature?range?:-40℃?to?+85℃
?
?
Electrical Specifications:
?
2.1?OCL?:P(1-2)=P(7-8)=350?uH?Min.?@?100?KHz,?100mV,with?8?mA?DC?Bias?. |
2.2?L.L:P(1-2)=P(7-8)=?0.6uH???Max.?@?100?KHz,?100mV |
2.3?Cw/w:?35PF?Max.?@?100?KHz,?100mV |
2.4?Turn?Ratio?:?P(1-2):J(1-2)=1CT:1CT±3%? |
??????????????P(7-8):J(3-6)=1CT:1CT±3%? |
2.5?DCR?:?1.2Ω??MAX. |
??????????J(1-3):J(2-6)=J(4-7)=J(8-6)=150Ω? |
2.6?Polarity:??P1&J1;P7&J3???In-Phase. |
2.7?Insertion?Loss?:-1.0dB?Max?@1~100MHz |
2.8?Return?Loss?:?-18?dB?MIN??@1-30?MHz |
????????????????-16?dB?MIN?@40MHz |
????????????????-12?dB?MIN?@50MHz |
?????????????????-10?dB?MIN?@60-80MHz |
2.9?Cross?Talk??:?-30?dB?MIN.?@1~100?MHz |
2.10?CMR??:?-30?dB?MIN.?@1~100?MHz |
2.11?Isolation?HI-POT:??P(1-2-3-7-6-8)?TO?J(1-2-3-6-4-5-7-8)@1500Vrms/? |
????1mA?Max/?2SEC. |
Material?specifications:
?
＊?Plastic?core:?PA66?Black(UL94V-0)?/PBT?Black(UL94V-0),optional
＊?Contact:gold?pin0.35mm?thick?phos?bronze?plated?nickel?then?with?6u’gold
＊?PCB?Terminal:Phosphor?bronze?,Tail-Tin?over?Nickl
＊?Housing:Phenolic,PA66Black?(UL94V-0)/PBT?Black(UL94V-0),optional
＊?Metal?shell:Copper?Alloy?,Tin?and?Nickel?plated
?
