Asia PP Series Portable Cone Crusher Machine

PP series portable cone crusher adopts the latest mobile crushing technology, which can fully reach the mobile crushing requirements of customers.

Product Introduction:
Feed size: 160-240mm

Capacity: 40-390t/h

For material: cobble, mountain rock( limestone, granite, diabase, basalt, andesite), tailings, aggregate chips to make sand. Applications: mine, carbon, recycle of demolish waste, concrete project, urban infrastructure, road building, and construction, etc.

Features:
1.Great mobility

2.Compact structure, convenient operation

3.Lower transportation cost

4.Higher applicability

5.Stable performance, easy maintenance

6.Flexible configuration

Equipped with SMH hydraulic cone crusher made by Sanme mining machinery, mobile cone crusher station PP series can produce aggregate of 10-45mm.Its arrangement device is installed laterally and is effected in closed and hydraulic way. It allows the arranging operation easier and faster. The arrangement can be realized via control box, which makes the system more suitable to arrange discharging opening in regular time.

Working principle:
Feed the material through feeder to cone crusher in regular way. After primary crushing, the material enters closed crushing circuit through inclined vibrating screen. The crushed material is conveyed out by the belt conveyor, and to be crushed continually. Mobile cone crusher station can remove inclined vibrating screen according to practical producing environment, and crush the material directly, in order to work together with other crushing equipment in a convenient and flexible way.

Configuration:

All the components of mobile cone crusher is mounted on vehicle, including: solid machine frame, cone crusher, vibrating feeder, vibrating screen, belt conveyor, control panel and control box.
