SNMP Managed media converter rack
- 10000 Case / Cases per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | 3c-link | Place of Origin | China | |
| Model Number | 3C-MUX-1802-R |
Product Description
1.8+1 Channel passive CWDM
2.Duplex SC adapter
3.Wide Pass Band
4.CWDM device
8 channel CWDM device
3c-Link's' Coarse wavelength division multiplexer (CWDM) utilizes thin film coating technology and proprietary design of non-flux metal bonding micro optics packaging. It provideslow insertion loss, high channel isolation, wide pass band, low temperature sensitivity and epoxy free optical path . 3c-Link's products are Telcordia qualification tested.
Features | Applications | |
|
|
Performance Specifications
Parameter | MUX | DEMUX | |
Operating Wavelength (nm) | 1470,1490,1510,1530,1550,1570,1590,1610 and Upgade interface | ||
Center Wavelength Accuracy (nm) | ± 0.5 | ||
Channel Spacing (nm) | 20 | ||
Channel Passband (@-0.5dB bandwidth) (nm) | >13 | ||
Insertion Loss Over Passband (Exculding Connectors) (dB) | <3.5 | ||
Channel Uniformity (dB) | < 1.0 | ||
Channel Ripple (dB) | < 0.5 | ||
Isolation (dB) | Adjacent | N/A | >30 |
Non-adjacent | N/A | >40 | |
Polarization Dependent Loss (dB) | < 0.10 | ||
Polarization Mode Dispersion (ps) | < 0.1 | ||
Directivity (dB) | >50 | ||
Return Loss (dB) | >45 | ||
Power Handling (mW) | 300 | ||
Operating Temperature (°C) | 0 ~ +70 | ||
Storage Temperature (°C) | -40 ~ +85 | ||
Dimensions (mm) | 19" Inch 1Unit Height |
Specifications may change without notice
CWDM Adapter:
