Soft PVC extruder screw cylinders
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | xhscrewbarrel | Place of Origin | China | |
| Model Number | XH301 |
Product Description
Soft PVC extruder screw cylinders
Specification
Screw diameter: ?15-300MM L/D:15-45
Barrel diameter: ?25-500MM Length:300-1000MM
Material
38CrMoAlA(JIS SACM645)
42CrMo(AISI 4140)
9Cr18MoV,stainless steel,etc
Screw Design:
The screw should be single flighted,constant pitch,with the pitch equal to the diameter and the
length equal to 24 diameters.It should be bored for cooling.Screw Flights should be flamehardened.
The screw should be AISI4140 chrome plated.Since flexible PVC compounds can cover a wide range of
hardnesses,the screw design and dimensions are less critial than for rigid pvc.
Mixing pins and other types of mixing sections are often incorporated in a screw design to enhance dispersion,espeically when adding concentrates to a naturalbased compound.Screws with mixing
pins typically have 12-14 flights in the metering section.
Barrier screws are still another type of design that can be used for extruding flexible PVC.
Parameter
Hard Chrome Plating treatment:
Thickness of Hard Chrome Plating Layer: 0.03-0.08mm
Hardness of Hard Chrome Plating Layer: ≥950HV
