7M Coaster Mini Bus Air Brake With EURO II Isuzu Technology, Hydraulic Clutch
- T/T L/C D/P D/A
- 7 days
You May Like
-
Single Phase Food Processing Machineries For Quail Egg Peeler 150KG/H
-
70L Diesel 6M Turbocharged Intercity Bus Transport With Inter Cooling System
-
Stainless Steel Food Processing Machineries With Single Phase
-
Energy Saving Sea Cucumber Dryer With 0.75KW Circulating Fan For Sea Cucumber
-
Adjustable Destoner Before Shell Peeler Of Peanut Processing Machines
-
3KW Mill For Peanut And Sesame Seed Production Machine For Nuts And Beans
Product Details
| Brand Name | HaoYu | Place of Origin | China | |
| Model Number | HY6700 |
Product Description
?7M Coaster Mini Bus Air Brake With EURO II? Isuzu Technology, Hydraulic Clutch
| Specifications | |||
| Model | HY6700 | ||
|
●DIMENSIONS & WEIGHTS |
|||
|
Overall dimension (mm) |
Length |
6990 |
|
|
Width |
2025 |
||
|
Height |
2670 |
||
|
Wheelbase (mm) |
3800 |
||
|
Thread? (mm) |
Front/rear |
1665/1525 |
|
|
Ground clearance? (mm) |
215 |
||
|
Seating capacity (persons) |
23+6 |
||
|
● ENGINE |
|||
|
Model |
CY4102BZLQ (EURO II)? Isuzu technology |
||
|
Type |
4-cylinder, in line, water-cooled, direct injection, diesel, turbocharged |
||
|
Inter-cooling |
|||
|
Bore & stroke? (mm) |
102x118 |
||
|
Displacement? (cc) |
3856 |
||
|
Max. Power? (hp/rpm) |
120/2800 |
||
|
Max. Torque? (N-m/rpm) |
343/1600 |
||
|
Fuel tank? (liter) |
90 |
||
|
● DRIVE TRAIN |
|||
|
Clutch |
Hydraulic, Single plate, dry type diaphragm spring |
||
|
Gearbox |
5 speed manual |
||
|
Max. gradeability (%) |
30 |
||
|
● CHASSIS |
|||
|
Frame |
Ladder shaped, ‘] ’ section |
||
|
Suspension, front/rear |
Leaf springs |
||
|
Shock absorber, front/rear |
Double action shock absorbers |
||
|
Steering |
Recirculating-ball? |
||
|
Brake? |
Type |
Air brake |
|
|
Front/rear |
Drums |
||
|
Power steering |
Available |
||
|
Min. turning radius (m) |
7.5 |
||
|
Tires |
7.50-16 |
||
|
FOB Shanghai |
|||
|
6 meters long version |
|||
| ? | ? | ? | ? |
|
MAIN EQUIPMENT |
|||
|
AM/FM cassette stereo |
△ |
Window curtains ? |
▲ |
|
Sun visor |
△ |
Air conditioning ?? |
▲ |
|
Front seat belts |
△ |
