Product Details
| Brand Name | VECAS | Place of Origin | China | |
| Model Number | RC |
Product Description
Certification:CE
Indoor Home electric Earth leakage circuit breaker for main power with 2 / 4 Pole
Technical data
|
Standard |
IEC1008,GB16916,BS EN61008 |
|
Rated Voltage (Un) |
2pole:230V AC |
|
4pole:230V AC |
|
|
Rated Current (In) |
25,40,63A |
|
Rated residual operating current (l△n) |
30,100,300,500mA |
|
Rated residual non-operating current (l△no) |
0.5 l△n |
|
Residual current off-tine |
≤0.1s |
|
Minimum value of rated making and breaking capacity (lm) |
1KA |
|
Rated conditional short-circuit current (lnc) |
ln=25,40A Inc=1500A |
|
ln=63A Inc=3000A |
|
|
Endurance |
on load:2000cycles |
|
off load:2000cycles |
INSTALLATION
On symmetrical DIN rail
