HXOT 501 Loop resistance tester High Voltage Testing Equipment 100A - 200A

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	FINEWORK		Place of Origin	China
Model Number	HXOT-501

Product Description

Delivery Time:2 to 4 weeks
Certification:ISO, CE

Quick Detail:

With big testing current With high output voltage, wide measurement range Test current from the 100A constant current power Adopt four-terminal connection method Quick test speed Simple operation, light weight, with microcomputer print

Description:

Intelligent loop resistance tester applies 100A constant current output. The maximum output voltage is 10V (2-3 times of conventional instruments),using fine cross-section of the test line, greatly reducing the labor intensity of the spot test. Testing process is all controlled from a single piece of automatic implementation, with high accuracy, good retest, single-button operation. Test data will show on LCD, results will be printed.

The current test meet the requirements of national standard about loop resistance test. The output voltage is high, measurement range is wide . Test current is from the 100A high-precision constant current power, which doesn’t need to manually adjust, and the test is quickly and accurately. Using the four-terminal connection method, effectively ruled out the effect of test line resistance. Test has a quick speed and good stability, and it displays data in about 10 seconds. The operation is simple, light weight, with microcomputer print, suitable for field work.

Applications:

Applicable to different working environments of various switches and electrical contact resistance, loop resistance and cable wires, the measurement of the contact resistance of the weld.

Specifications:

Test current	100A/200A
Range	0-20 mΩ
Resolution ratio	Min 0.1μΩ
Accuracy	±(0.5%±2digits)
Power	1000W
Operation Mode	Continuous measurement

Competitive Advantage:

Safer design More durable lifetime More stable performance More elaborate manufacture Top quality in China Good Service Professional Staff
