Cr12 Shelf Cold Roll Forming Machine High Efficiency Guide Frame

Quick Detail:

1. Shelf roll forming machine

2. Equipment production capacity: width≤400mm, thickness of steel material: 1-2.5mm

3. Production speed: 8-15m/min

4. Total power: about 21.5kw

Description:

The equipment is consisted with auto-de-coiler, guide frame, lever/feeding section, continuous bottom

hole punching section, forming section, positioning and cutting section, collection table and electrical

control system etc. Shelf forming machine is Jiangyin Bosj Technology Co.,Ltd. According to market

demand by the collection year production cold rolling equipment experience independently designs a

series or products.Product: Shelf column, Shelf crossbeam, Shelf stay rod, Shelf plywood etc.
?

Functions and Features:

Forming processing: Auto de-coiler ---- guider ---- lever, feeding ---- continuous bottom hole punching ----

forming ---- positioning and cutting ---- collection table

Specifications:

Equipment capacity:

1, Equipment production capacity: width≤400mm, thickness of steel material: 1-2.5mm

2, Production speed: 8-15m/min

3, Total power: about 21.5kw

Main parts technical parameters:

1, Auto-de-coiler

a. Inner expansion type, max.? loading? 5 tons

b. Coiler inner diameter: ￠510mm, outer diameter: ￠1200mm

c. Speed is controlled by electrical conduction.

2, Lever and feeding section

a. Correction roller: up 4sets / down 5 sets

b. Lever range : max. width 400mm, max. thickness 1—2.5mm

c.? Feeder is high speed roller type feeding.

3, Bottom hole punching section

a. Punching press: JE21-80

b. Mould material Cr12

4, Main forming machine

a. Forming station: 18 stations

b. Max. raw material feeding width : 400mm

c. Shaft diameter: ￠70mm, material: 40 Cr

d. Material of roller: GCr15, quenching treatment, hardness HR C56-62o

e. Motor power: 30kw motor, ZQ500 reducer.

5, Cutting device

a. Hydraulic cutting blade

b. Hydraulic station: 4kw

c. Material of blade:? Cr12, quench treatment

Competitive Advantage:

1. our machines are famous for good quality and inexpensive ,

2. we can supply good after sevice .

3. one year guarantee.

4. We can design the machines according to customers’ special requirement .

5. We have professional team for service.

PHOTOS:
