40Cr Z Purlin Roll Forming Machines , 380V Hydraulic Pressure Cutting

Quick Detail:

?Z purlin roll forming machine

?Machine capacity: width≤500mm, thickness:1-3mm

Description:

It is making up of de-coiler, guide rack, roll forming, correction, cutting-to-length (punching),

collection table, electrical control system etc.

Functions and Features:

?Unit performance

1,Machine capacity: width≤500mm, thickness:1-3mm

2,Product speed: 0-15m/min

3,Total power: about35.5kw

4,Pressure:380V

5,Occupy ground area:? length 18m x width3m

Specifications:

1. De-coiler: de-coiler, Inner expanding type, capacity:5T

2. Guide Rack: two pairs of lever rollers and four pairs of standing rollers.

3. Flatting number: 9 sets

4. Roll forming

5. Type: GY180

6. Rack: Cast iron Torii type,?? material: HT200

7. Roll forming rack:? 12 sets

8. The diameter of the roller axis:φ80mm, roller surface:500mm

9. Material: 40Cr?? quenching treatment HB280

10.Drive type:? every rack has one gear power distribution box.

11.Main power: 30kw?? frequency conversion, ZQ500 reducer

12.Material: GCr15, Quenching, Hardness: HRC58-62o

13.Assistant roller rack:?? 4 sets

14.Adjust part:? Turkey emendation type(three-dimensional emendation)

15.Cutting-to-length device: Hydraulic pressure cutting,power:5.5kw

Competitive Advantage:

1. our machines are famous for good quality and inexpensive ,

2. we can supply good after sevice .

3. one year guarantee.

4. We can design the machines according to customers’ special requirement .

5. We have professional team for service.

PHOTOS:
