Gas Pressure 5 Gallon Water Filling Machine , Plastic Bottle Filling Line
- T/T L/C D/P D/A
- 7 days
You May Like
-
Electric 3 / 5 Gallon Water Barreling Machine , Aseptic Filling Machinery
-
Automatic 5 gallon Water Filling Machine / Jar Filling Equipment , 240V 12KW
-
2 - 10 Heads 5 Gallon Water Filling Machine , PLC Washing Filling Capping System
-
Rotary 3 Gallon / 5 Gallon Water Filling Machine For Pure Water / Mineral Water
-
QGF Series Barrel 5 Gallon Water Filling Machine , 10 Heads 1200BPH
-
5 Gallon Water Filling Machine , 3 In 1 Liquid Filling Production Line
Product Details
| Brand Name | XinMao | Place of Origin | China | |
| Model Number | QGF |
Product Description
Certification:CE,ISO9001:2001,BV
Gas Pressure 5 Gallon Water Filling Machine , Plastic Bottle Filling Line
Quick Detail:
Filling temperature: 20-40degree Bottle volume: 5 gallon 20L Filling capacity: we can offer 100bph-1200bph After service: with professional engineer to customer factory to installment and train Material: sus 304/316 Packing: wooden package Voltage: 380V 50Hz/ by order Power: 5-18KW
Description:
Automatic 3/5 gallon water filling machine???
This Series Barrel Filling Machine is specially designed to produce 3 or 5 gallon barrel drinking water, production line, which is ideal for production for mineral water, distilled water and pure water. The use of top quality stainless steel guarantees it high-performance resistance of corrosion and easiness of cleaning.
With major electrical components coming from SIEMENS and OMRON, and original components for gas path imported from AIRTAC, combined with interior and exterior spray nozzles for cleaning barrels provided by know-how enterprise of American spray companies. This machine is of compact design, high efficiency, accurate and sensitive response and high automation level to ensure its stability and reliability as an entegrated (machine, electricity and gas) full automatic barrel filling line.
Technical standard
|
Model? |
QGF100 |
QGF250 |
QGF300 |
QGF450 |
QGF600 |
QGF900 |
QGF1200 |
|
Filling?heads |
1 |
2 |
2 |
3 |
4 |
6 |
10 |
|
Volume(L) |
18.9 |
18.9 |
18.9 |
18.9 |
18.9 |
18.9 |
18.9 |
|
Barrel?size(mm) |
φ270×490 |
φ270×490 |
φ270×490 |
φ270×490 |
φ270×490 |
φ270×490 |
φ270×490 |
|
Capacity(b/h) |
100 |
250 |
300 |
450 |
600 |
900 |
1200 |
|
Gas?pressure(Mpa) |
0.4-0.6 |
0.4-0.6 |
0.4-0.6 |
0.4-0.6 |
0.4-0.6 |
0.4-0.6 |
0.4-0.6 |
|
Gas?consumption(m/min) |
0.37 |
0.37 |
0.6 |
0.8 |
1 |
1.5 |
1.8 |
|
Motor?power(kw) |
1.38 |
1.75 |
3.8 |
3.8 |
7.5 |
9.75 |
13.5 |
|
Weight(kg)? |
680 |
800 |
1500 |
2100 |
3000 |
3500 |
4500 |
Our?customer?cases
