2500cd / P37.5 DIP 546 Mesh LED Display With Aluminum Cabinet
- T/T L/C D/P D/A
- 7 days
You May Like
-
High Resolution 3500cd / DIP 546 Mesh LED Display With Cree LED Chip
-
P20 DIP 546 Constant Current / 1/2 Scan Mesh LED Display for Events
-
Fix / Hanging Video TB SDI Mesh LED Display , Led Grid Curtain
-
SMD Indoor Full Color LED Display
-
IP65 / IP43 Indoor Full Color LED Display
-
Indoor Full Color LED Scrolling Display
Product Details
| Brand Name | LED-HERO | Place of Origin | China | |
Product Description
Certification:CE, RoHS, UL, EMC, ISo9001
2500cd / ㎡ P37.5 DIP 546 Mesh LED Display with Aluminum Cabinet
Quick Detail:
1.??? Good transparency
2.??? Light weight
3.??? Easy install
4.??? Convenient to move
5.??? Beautiful design
Description:
1: Ultra-thin design with high permeability, reduce the weight of the display screen to the limit.
2: Adapt to each pixel, each module, each box and the entire screen, point by point correction, Prefect white balance.
3: The unique design of the drive circuit, so that the refresh rate easily reach to 3000HZ.
4: Use the outdoor bright LED lamp, the led display can show a wider viewing angle, great color mixing, making the displaying color more vivid.
5: The rugged aluminum housing, durable and light weight.
6: IP66 protection design, support for long-term outdoor use and can be resistant.
7: The cabinet is designed using a new type of scalability hanging style, quick and easy installation and maintenance more convenient.
8. Good heat dissipation.
Applications:
The product applies to rental and always use in the? Stage, bar, hotel lobbies, upscale restaurants, building glass curtain wall, and a variety of entertainment and events large occasions.
Specifications:
| Specification | P37.5 DIP |
| Item 1 ---LED Chip? | |
| Brand? | Epistar ,Opto , Cree , Nichia? |
| Country of Origin | Taiwan. United States. Japan? |
| Span life? | ≥ 100,000 Hrs |
| Item 2--- Modules? | |
| Pixel Pitch? | PH 37.5 |
| LED configuration | DIP 546 |
| LED Composition | 1R1G1B |
| Modules size? | 300? (L)? mm? *?? 300? (H) mm |
| Driving IC? | MBI 5024/5041 |
| Driving Method? | Constant Current / (Static)? |
| Item 3--- Cabinet? | |
| Cabinet size? | 600? (L)? mm? *?? 600? (H) mm |
| Cabinet Material? | Aluminum? |
| Installation Method? | Fix / Hanging / Rental?? |
| Cabinet weight? | 10 Kg? |
| Item 4--- Display screen | |
| Brightness? | ≥? 2500cd/㎡? |
| Viewing Angle | |
| Refresh Rate? | ≥800 Hz |
| Fresh Requency? | ≥60Hz |
| Input Voltage? | AC220V/50Hz or AC110V/60Hz |
| Power Consumption? | Max.:250 W/㎡??? Average:90W/㎡ |
| Front and Back protective Grade? | |
| Signal? Output? | HDMI DVI VGA RGBHV PbPr (HDTV) |
| Signal Connection? | Video? TB SDI? |
| Controlling System? | Linsn/ Colorlight / Nova/ DB Start … |
| Operating System? | Windows98/me/2000/NT/XP Window7 ,Vistar |
Competitive Advantage:
1.??? The display can be suspended or vertically mounted as different demands from leasing or purchasing users. Convenient design on the connection structure, two cabinets can be connected easily in 10 second without any tools.
2.??? The green light and red light on the back of the cabinet makes it easier to detect the problem on signal and power source, save a lot of trouble for you on maintenance.
3.??? Nature heat dissipation without using any specific equipment, allow the working of the screen more quiet.
4.??? Super-slim cabinet design, aluminum alloy cabinet makes the screen extremely lightweight, perfect for stage decoration usage.
5.??? The flatness of the display is greatly improved by its high-precision processing technology, one card for one cabinet design, highly improve the refresh rate.
Tag:
Led mesh curtain; led grid curtain; led grid display; full color led mesh display; led curtain
