Mobile tower communication antenna

MEGATRO Mobile tower communication antennas are, typically, tallstructures designed to support telecom accessories with antennas fortelecommunications and broadcasting, including television.

Over three decades of industry experience in this domain enablesMEGATRO to successfully undertake designing, fabrication, galvanizing anderection work of MOBILE TOWERS COMMUNICATION ANTENNA.

Our attractive and multi-functional Mobile tower communication antennas are facing immense demand from everycorner of globe for their technical, scientific and compact designspecifications. These are developed, designed and installed with the assistanceof our experienced, qualified and expert engineers and technocrats. We offercost effective range of development and installation service regarding as anadditional installation service. These are further, designed for bothgovernment and civil communications and suitable for both far-off andshort/long distance communications.

These Mobile tower communication antennas arefabricated by us keeping into consideration clients' specifications pertainingto size, weight, heights & orientation of antenna, wind velocity oflocation etc. Prior to installation, we also implement site survey and soil investigation.Further, we also pay attention towards the timely execution of our turnkeyprojects.

After fabrication all Mobiletower communication antennas are delivered to the galvanizing facility tobe Hot DIP Galvanized. Towers are processed through the facility by CausticCleaning, Pickling, and then Fluxing. These strict procedures insure years ofmaintenance free towers.

MEGATRO Mobile tower communication antennas canaccommodate a variety of step bolts and other accessories and mounts.  MEGATRO provide Mobiletower communication antennas design with below requirements

Design Requirements and Basic of Design
MEGATRO TOWERS will guarantee theoverall safety of the tower. MEGATRO TOWERS will submit design calculation reportfor member design of tower and overall structural stability of the structure,which is signed by a charted structural Engineer.
MEGATRO will supply the skeleton toscale, showing the assembly of the structures, the antenna mounting levels,other detail drawings etc.
The calculation method to be adopted for tower design will be decided by MEGATRO TOWERSwith the consent of the client.
All materials will comply with Chinese standard (hereinafter called GB), BritishStandard (hereinafter called BS), Japanese Industrial Standard (hereinaftercalled JIS) or equivalent standards. The permissible stress of the materialswill comply with BS, standard by Architectural Institute of Japan (hereinaftercall AIJ) or equivalent. The standards adopted for all materials will be statedseparately.

General Design Criteria
Mast will be designed based on GB, BS 8100, TIA/EIA-222-G-2006, IS 802 &IS875 or equivalent international standards.
The wind loading on the tower and antennas mounted on it will withstand aground level wind velocity of 140 Km/h and survival speed of 180 Km/h includingwith height in accordance with latest BSI CP3: Chapter V: Part 2: BritishStandard (BS)
Antenna that will be considered when it calculates wind areas will be Six GSMantennas, Two each 600 mm diameter microwave dishes & one 1.2m ? Microwaveplus all the feeders for GSM and MW antennas.
Allowance will be given to the effective windage area of the following:
Feeder runway
Feeders
Platforms and guard rails
Ladder and ladder guards
MEGATRO submit the complete data showing the drag factor from various angles ofwind on the antenna offered.

Other Information
Availability size: Based on the customer's requirements.
Material: Chinese material or as per clients requirement
Package: Both parties discuss before delivery
Terms of Payment: L/C, T/T
Minimum Order Quantity: 3 tons
Port of Loading: Qingdao Port
Lead Time: One month or based on the customer's needs
Performance Standard
Besides conform to the drawing and design, the materials and fabrication oftower components shall conform to the Chinese Standard or other standard whichclients can accept.
