Automatic Boiler 10T Tank Rotating Welding Rotators / Tank Rool
- 0 Twenty-Foot Container per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
100Tons Pipe Welding Rotator
-
Lead Screw Adjustable Pipe Welding Rotator
-
Variable Frequency Control Pipe Welding Rotator 100T For Tank / Pipe Welding
-
Petro-Chemical Industries Pipe Welding Rotator With 2 490 60 Metal Rollers
-
6 60 m / h Self Aligning 40T Pipe Welding Rotator With 400 120 Rubber Roller
-
Customized Vessel / Pipe Welding Rotator 40T For Power Station Construction
Product Details
| Brand Name | H-WELDING | Place of Origin | China | |
| Model Number | HGZ-10 |
Product Description
Certification:Certification of original
Automatic Boiler 10T Tank Rotating Welding Rotators / Tank Rool
Quick Detail:
The self- align/adjusting rotator is suitable for circular pipe/tank/vessel welding; The distance between wheels can be adjustable by it self. There are several specifications for customer choice; we also can special design according to customer’s requirements.Description:
This series welding rotator has the types of self-aligned, conventional which are suitable for welding, polishing, assembly for pipe/tank/vessel longitudinal and transverse seam welding.??
Welding rotator can be auto adjusted according to the size and weight of cylinder, VFD rotary speed control, improving the reliability of operation.
Our company also can customize welding rotator in all varieties according to client\'s requirements.
Applications:
It used in many industries such as pressure vessel, boiler, freezing equipment, power station construction, metallurgical, engineering machinery, marine building, and petro-chemical industries etc.
Specifications:
|
Type |
Max loading(kg) |
Range of suitable work piece(mm) |
Dia and width of the wheel(mm) |
roller linear velocity(m/h) |
Power of motor(kw) |
Way of setting |
|
|
Rubber roller |
Metal rollers |
||||||
|
HGZ-5 |
5000 |
Φ250-2300 |
Φ250×100 |
2×Φ240×20 |
6-60 |
0.75 |
Variable frequency control? |
|
HGZ-10 |
10000 |
Φ320-2800 |
Φ300×120 |
2×Φ290×25 |
6-60 |
1.1 |
|
|
HGZ-20 |
20000 |
Φ500-3500 |
Φ350×120 |
2×Φ340×30 |
6-60 |
1.5 |
|
|
HGZ-40 |
40000 |
Φ600-4200 |
Φ400×120 |
2×Φ390×40 |
6-60 |
3 |
|
|
HGZ-60 |
60000 |
Φ750-4800 |
Φ450×120 |
2×Φ440×50 |
6-60 |
4 |
|
|
HGZ-80 |
80000 |
Φ850-5000 |
Φ500×120 |
2×Φ490×60 |
6-60 |
4 |
|
|
HGZ-100 |
100000 |
Φ1000-5500 |
Φ500×120 |
2×Φ490×70 |
6-60 |
5.5 |
|
|
HGZ-150 |
150000 |
Φ1000-6500 |
according to customer requirement |
6-60 |
2×3 |
Drawing:
Competitive advantage:
1. Main electric elements are Siemens/Schneider.
