800nits IP65 Full Color Indoor Led Display Board

No.

Specifications

1.???????

LED chip

Taiwan/Silan/Cree/Cree Cotco

2.???????

Physical Pixel Pitch

10mm

3.???????

Physical Pixel Density

10000dots/m2

4.???????

Pixel composition

1Red, 1Green,1Blue

5.???????

Moduel Size

320mm*160mm

6.???????

Moduel resolution

32dots*16dots

7.???????

Cabinet thickness

< 170 mm

8.???????

Bracket of cabinet

Easy to install onto the LED cabinet and unistall .

9.??? ?

Brightness

≥ 800nits

10.??? ?

Colors

16.7million

11.??? ?

Viewing angle

Horizontal ≥120°, ??Vertical? : ≥? 120°??

12.??? ?

Viewing distance

8m -150m

13.??? ?

Soft Rubber Mask

To protect player and LED display itself .

14.??? ?

Scan frequency

≥600 Hz

There will be one receive card in each cabinet? ,so that the LED display won\'t sparked .Also it is very easy to move and connetct

15.??? ?

Video Frame Rate

≥150 fps

16.??? ?

Color temperature

6500°K to 9500°K adjustable

17.??? ?

Control method

Controlled by PC, synchronous display

18.??? ?

Life span( half brightness)

≥100,000 hours

19.??? ?

Weight

less than 45Kg ?/sqm

20.??? ?

IP rate

IP65 ( front side and rear side)

21.??? ?

Lowest?power consumption

50W/sqm

22.??? ?

Peak power consumption
