Steel crawler Track Undercarriage
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | kemer | Place of Origin | China | |
| Model Number | sales@bonnyhydraulic.com |
Product Description
?track undercarriage, drilling rig steel track undercarriage
We are an experienced company specialized in manufacturing steel track undercarriage and rubber track undercarriage. we make custom track systems for your mobility needs, and our track undercarriage can carry up to 50ton,and supporting dual-speed final drive and travel 0-7km/h at grades up to 60%.
APPLICATION
Special design catered to customer specifications. With years of experience we can offer the track design flexibility, rapid response and solutions that are always highly effective.
For application on drilling rigs, excavators, crushers, cranes, aerial platform, etc. with high efficiency and adaption of vile working condition.
If you have any question or need any help, please feel free to contact with sales@bonnyhydraulic.com.
we can also custom built the undercarriage with load capacity from 1 ton to 50 ton based on your requirements.
MODEL | Dinamic | Static | Weight | Press. Bar | oil flow | Torque | Grad. | Speed |
ST-3500 | 3500 | 4000 | 750 | 220 | 35 | 4723 | 65% | 2/3.2 |
ST-6000 | 6000 | 7000 | 1350 | 220 | 55 | 8330 | 65% | 2/3.7 |
ST-8000 | 8000 | 9500 | 1830 | 300 | 82 | 11700 | 65% | 2.8/4.7 |
ST-10000 | 10000 | 11300 | 2350 | 350 | 100 | 14800 | 65% | 3/5.1 |
ST-12000 | 12000 | 15000 | 2950 | 350 | 124 | 22500 | 65% | 2.9/4.9 |
ST-15000 | 15000 | 18000 | 3300 | 350 | 140 | 24000 | 65% | 3.2/5.5 |
ST-20000 | 20000 | 25000 | 4300 | 350 | 220 | 38000 | 65% | 3.5/5.4 |
ST-30000 | 30000 | 37000 | 6500 | 330 | 260 | 59000 | 65% | 2.5/4.6 |
ST-40000 | 40000 | 480000 | 7100 | 350 | 290 | 72800 | 65% | 2.3/4.3 |
