metal keypad access control S100EM

Product features

Working Voltage: DC12V±10%

Waterproof degree: IP68

Environment Temperature: -45℃~60℃

Environment Humidity: 10%~90%

Electric lock output: ≤3A

Alarm output: ≤20A

Output short-circuit protection time: ≤100µS

Open-door time: 0~99 seconds (adjustable)

Size: 120×80×25mm

With Anti-theft alarm output for external alarm device

With bult-in-anti-theft equipments

Support enrolling cards continuously

Perfect design, with backlight and fashion silver finish

Waterproof design for outdoor use

Strong standalone function device, can be used as WG26reader alone

Capacity: 2000 user’s cards, 2000 codes

Access ways: cards, code, card + code

Lower power: static current less than 30mA

Support only keypad

Users can reset private passwords

Wiegand output W26 for card and W34 for codes

Use keypad to delete lost cards for safety

Short-circuit protect: when relay or alarm output short circuit, it will shut up in 100µS

The unit is a single door multifunction standalone access controller, which is an ideal choice for door access for shops, households, commercial and industrial applications, such as, factories, warehouse, laboratories, banks and prisons.
