High Pressure Diesel Fuel Filter 16405-02N10 , Cartridge Filter

Brand Name	RAINBOW		Place of Origin	China
Model Number	16405-V5710

Delivery Time:30 working days after advance payment

High Pressure Diesel Fuel Filter 16405-02N10 , Cartridge Filter

Quick Detail:

High Quality OE Replacement/Auto Fuel Filter 16405-02N10 for CARBODIES & LTI. A fuel filter is a filter in the fuel line that screens out dirt and rust particles from the fuel, normally made into cartridges containing a filter paper.
?

Description:

Fuel filters serve a vital function in today\'s modern, tight-tolerance engine fuel systems. Unfiltered fuel may contain several kinds of contamination, for example paint chips and dirt that has been knocked into the tank while filling, or rust caused by moisture in a steel tank. If these substances are not removed before the fuel enters the system, they will cause rapid wear and failure of the fuel pump and injectors, due to the abrasiveaction of the particles on the high-precision components used in modern injection systems. Fuel filters also improve performance, as the fewer contaminants present in the fuel, the more efficiently it can be burnt.
Fuel filters need to be maintained at regular intervals. This is usually a case of simply disconnecting the filter from the fuel line and replacing it with a new one, although some specially designed filters can be cleaned and reused many times. If a filter is not replaced regularly it may become clogged with contaminants and cause a restriction in the fuel flow, causing an appreciable drop in engine performance as the engine struggles to draw enough fuel to continue running normally.

Applications:

CARBODIES & LTI

Specifications:

Item	Value
Outer Diameter	93
Height	120
Thread Size	3/4-16UNF
Type	Spin-On Fuel Filter
Material	Metal, 100% Filter Wood pulp Paper
Sealing Material	O-ring
Filtration Efficiency?	≥ 99.7 %
Heat Resistance of Rubber Sealing Washer	From -45 °C to 150 °
Stay in High Temperature Oil	135°C for 198 hours
Maximum?Flow?	20?gpm
Maximum?Working?Pressure	50?psi
Filter Paper Available	10micron 30 micron 60 micron
Color	According to customer’s requirement
Packing	According to customer’s requirement

Competitive Advantage:

RAINBOW is able to design and produce different models of auto filters, including air filters, oil filters, fuel filters, filter elements, and cabin filters. RAINBOW’s filters are compatible with many brands, such as GM, ISUZU, TOYOTA, NISSAN, HONDA, HYUNDAI, FORD, MAZDA, SUBARU, CHRYSLER, SKODA, BENZ, AUDI, FIAT, BMW, PEUGEOT, VOLVO, RENULT, SAAB, AMC, SAYURN, MITSUBISHI, etc. More important, small order is available to meet our customer.

Tag:Diesel Fuel Filter, OE Replacement Fuel Filter,
