Home > Products > SMD LED Display > Indoor Full Color SMD LED Display For Airport Advertising , 5MM Pixel Pitch
Indoor Full Color SMD LED Display For Airport Advertising , 5MM Pixel Pitch
- T/T L/C D/P D/A
- 7 days
You May Like
-
P7.62 1R1G1B Indoor Full Color SMD LED Display Screen For Fashion Shows
-
P5 SMD LED Display
-
Indoor SMD LED Displays
-
Full Color Stage P10 LED Display SMD 3528 , 1400 Nits DVI Connector
-
P16 Outdoor DIP LED Display Boards , 256*256M Module IP65 Waterproof
-
P25 Outdoor DIP LED Display , LED Video Walls Advertising Billboard
Product Details
| Brand Name | lysonled | Place of Origin | China | |
| Model Number | P5 Indoor LED Display Screen |
Product Description
Certification:CE ROHS ISO
Indoor Full Color SMD LED Display For Airport Advertising , 5MM Pixel Pitch
Quick Detail:
1) Stable quality:Opto + Silan chipset;
2) High brightness:1500 ~1800nits;
3) Scan driver:1/16 current;
4) Module size(L*W):160*160mm;
Description:
P5 Indoor Full Color LED Display Screen
5mm pixel pitch,1R1G1B,40000 dots/sqm,P5 Indoor Full Color LED Display Screen creates comfortable brightness and energy saving,display variable video resources,animations,messages to attract attention. We can see P5 Indoor Full Color LED Display Screen in many occasions,like Sports,advertising,traffic,entertainment,stage,events,stations,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc
Applications Occasions:
Sports,advertising,traffic,entertainment,stage,events,stadium,train station,bus station,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc
Specifications:
P5mm Indoor Full Color LED Display Screen:
|
Pixel configuration |
SMD3528 1R1G1B 3 in 1 |
|
LEDs configuration |
Red:wave length: 625~630nm;300-400mcd |
|
Pixel pitch(mm) |
5 |
|
Pixel density(dots/sqm) |
40000 |
|
Calibrated brightness(cd/sqm,nit) |
1800 nits(adjustable) |
|
Calibrated brightness proportion ratio |
R:G:B = 3:6:1 |
|
Contrast ratio |
4,500:1 |
|
Brightness adjustment(dimming) |
100 grade auto/manual-adjustment |
|
View angle(degree)(50% brightness) |
V140/H140 |
|
Color capability |
4.4 trillion |
|
Refresh rate(Hz) |
>800 Hz |
|
Frame frequency(Hz) |
>60 Hz |
|
Interface port |
DVI interface(DVI connector) |
|
Input signal |
VGA, Video, AVI, MOV, MPG, DAT, VOB etc. |
|
LED Drive |
Constant-current |
|
Lifetime(hours)(50% brightness) |
100,000 hours |
|
Signal transmission direction |
Horizontal |
|
Operating temperature(Celsius degree) |
-30 ~ 65 |
|
Storage temperature(Celsius degree) |
-35 ~ 70 |
|
Operation humidity(RH) |
0-95% |
|
Operation humidity(RH) |
0-99% |
|
Service |
Front and back service optional |
|
Control mode |
Synchronous & asynchronous available |
|
Communication options |
Wire Ethernet, Fiber Ethernet,RF wireless,GPRS |
|
Power |
120/240 VAC single phase(50-60Hz) |
|
Maximum power consumption(W/sqm) |
800 |
|
Average power consumption(W/sqm) |
