Home > Products > Rj45 Single Port > Single Port 1X1 Vertical Magnetic Rj45 Jack CAT5 With Side Entry

Single Port 1X1 Vertical Magnetic Rj45 Jack CAT5 With Side Entry

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 0 per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	DGKYD		Place of Origin	China
Model Number	KRJ-109NL

Product Description

Delivery Time:Lead-time 7days
Certification:GP ROHSSGSISO9001

1.Type: rj45 single port

2.TAB direction: Down

3.Shieded:YES

4.LEDS:YES

5.EMI?finger:YES

6.Length: 21.3mm?

Single?Port?1X1?Vertical?Magnetic?Rj45?Jack?CAT5?With?Side?Entry

Descriptions:

＊?10/100Base-Tx?RJ45?single?port?1X1?Vertical?with?LEDS?with side entry

＊?Single?port?1X1?Tab-Down?RJ45?with?internal?magnetics?????????????

＊?Internal?magnetics?are?100%?electrically?tested?for?HI-POT?and?functionality

＊?Suitable?for?CAT5&6?fast?Ethernet?Cable?or?better?UTP

＊?350uHminimum?OCL?with?8mA?bias?current

＊?High?performance?for?maximum?EMI?suppression

＊?Minimum?1500Vrms?isolation?per?IEEE?802.3?requirement

＊??ROHS-6?peak?wave?solder?temperature?rating?260℃

＊?Operating?temperarure?range?:0℃?to?+70℃

＊?Storage?temperature?range?:-40℃?to?+85℃

＊?Number?of?positions:8

＊?Number?of?contacts?loaded:8

＊?Shieded:YES

＊?Rohs?compliant

＊?Length:21.3mm

＊?LEDS:YES

＊?EMI?fingers:YES

＊?LEFT?LED:Green,RIGHT?LED:Yellow

＊?Usage:KRJ-109NL

2.ELECTRICAL?SPECIFICATIONS?@25℃

2.1?OCL?:P(1-2)=P(3-6)=350?uH?Min.?@?100?KHz,?100mV,with?8?mA?DC?Bias?.

2.2?L.L:P(1-2)=P(3-6)=?0.5uH???Max.?@?100?KHz,?100mV

2.3?Cw/w:?35PF?Max.?@?100?KHz,?100mV

2.4?Turn?Ratio?:?P(1-2):J(1-2)=1CT:1CT±3%?

???????????????????????????P(3-6):J(3-6)=1CT:1CT±3%?

2.5?DCR?:?1.2Ω??MAX.

?????????????????J(1-3):J(2-6)=J(4-7)=J(8-6)=150Ω?

2.6?Polarity:??P1&J1;P3&J3???In-Phase.

2.7?Insertion?Loss?:-1.1dB?Max?@0.3~100MHz

2.8?Return?Loss?:?-16?dB?MIN??@1-30?MHz

????????????????-14.4??dB?MIN?@40MHz

????????????????-13.1??dB?MIN?@50MHz

????????????????-12??dB?MIN?@60-80MHz

2.9?Cross?Talk??:?-35?dB?MIN.?@1~100?MHz

2.10?DCMR??:?-25?dB?MIN.?@1~100?MHz

2.11Isolation?HI-POT:??P(1-2-3-4-5-6-7-8)?TO?J(1-2-3-6-4-5-7-8)@1500Vrms/?

????1mA?Max/?2SEC.

Material?specifications:

＊?Plastic?core:Glass?fiber?filler?PBT?Black(UL94V-0)

＊?Contact:gold?pin0.35mm?thick?phos?bronze?plated?nickel?then?with?6u’gold

＊?PCB?Terminal:Phosphor?bronze?,Tail-Tin?over?Nickl

＊?Housing:Phenolic,?PBT?Black?(UL94V-0)

＊?Metal?shell:Copper?Alloy?,Tin?and?Nickel?plated
