Double Rotary Tablet Compression Machine For Irregular Tablets , 4kw

Brand Name	wangqun		Place of Origin	China
Model Number	ZP31D

Delivery Time:7-10 days
Certification:ISO 9001:2000，CE

Double Rotary Tablet Compression Machine For Irregular Tablets , 4kw

Quick Detail:

rotary tablet press,tablet press machine double-press, continuous automatic tablet press press round tablets and irregular tablets. Number of dies:31sets Max. Pressure:80kn Max. Dia. of Tablet:22mm Max. Production Capacity:93000pc/h Warranty:1 year

Description:

ZP31D rotary tablet press is double-press, continuous automatic tablet press for pressing granular raw materials into tablets. It is mainly used in pharmaceutical industry as well as chemical, food, electronic industries.

Produce all kinds of round tablets and irregular tablets. Fitted with transparent glass doors and windows, the state of pressing can be observed clearly, The side panels can be opened entirely for easy internal cleaning and maintenance. The external casing is in totally closed-form in stainless steel. Stainless steel internal table is available to maintain the surface gloss, prevent cross-contamination and to meet GMP requirements. The lay-out of all the controllers and the operate parts is reasonable. The electric VVVF speed control device is used for easy and stable operation as well as safety and accuracy consideration. An overload protection unit is included in the system to avoid the damage of the punches and apparatus. When overload occurs, the machine stops automatically. It is mechanical and electrical integration. Closed in a square oil tank under the bottom of the machine body, the driven system is completely isolated to avoid oil contamination. Submerged into the oil tank, the system is easy to cool and wear resistant. Dust collector is installed to remove dust automatically. Easy to wear parts of the machine, such as top rail, feed, and hopper, worm drive, etc. has interchangeable structure with old ZP33-based products, conducive for standardization, universal application and serialization. Punch dies are interchangeable with? ZP17,ZP27,ZP33D tablet press .

Applications:

It is mainly used in pharmaceutical industry as well as chemical, food, electronic industries.Produce all kinds of round tablets and irregular tablets.

Specifications:

Number of dies	31 sets
Max. Pressure	80KN
Max. Dia. of Tablet	22mm
Max. Thickness of Tablet	10mm
Max. Depth of Filling	20mm
Max. Production Capacity	93000 pc/h
Max Turntable Rotation Speed	0-35 r/min
Overall Size(L*W*H)	980*1240*1690mm
Net Weight	1850kg
? Motor Power	4kw

Competitive Advantage:

foodstuff, chemical, electronic and other industries press granule material into round/ lump/annular tablets external part of the machine is fully-enclosed double-press, continuous automatic tablet press meet the GMP requirement Dust collector is installed
