- Vonlin industry Co.,Ltd
-
Jiaxing, Zhejiang, China
- Main products: AC DC Battery Charger
Home > Products > AC DC Battery Charger > Intelligent LED light AC DC Battery Charger With 12.6V 0.3A
Intelligent LED light AC DC Battery Charger With 12.6V 0.3A
- T/T L/C D/P D/A
- 7 days
You May Like
-
Wall Mounted AC DC Battery Charger 12.6V For PSP / MP3 / MP4
-
Auto Cellphone AC DC Battery Charger For Rechargeable Battery
-
4.2V - 16.8V 1A AC DC Battery Charger , Li-Ion Battery Charger
-
Automatic 1.5A AC DC Battery Charger For Iphone Ipad Cellphone
-
Short Circuit AC DC Battery Charger , Airsoft Gun Charger
-
CCCV Mode Lithium Polymer Battery Charger , Laptop Charger
Product Details
| Brand Name | OEM/ODM/Neutral | Place of Origin | China | |
| Model Number | V11.1-03-W |
Product Description
Certification:CE
Intelligent LED light AC DC Battery Charger With 12.6V 0.3A
Name:? Universal Smart battery charger, automatic intelligent battery charger, fast charger Input:100-240Vac 50-60Hz 1.0A Output:12.6Vdc charging current:300mA Dimension: 3.5\'\' L x 1.5\'\' W x 1\" H.3.5\'\' (89mm)L x 1.5\'\'(38mm) W x 1\"(25mm) H Weight:180g Charging time = (1.5 x mAh rate of battery) / 300 mA Plug: US/UK/EU AC input Feature: Short circuit protection, Over temperature protection, CCCV charging mode, CE approved Application: Medical care system, Li-ion/Li-polymer battery packs, Airsoft gun, RC Car, RC toy, RC Plane, E-bike, RC Air plane, Diving light, Bicycle, Power tool, Halogen bike light battery, LED Light Efficiency: 80%(min)Quick Detail:
12.6V 0.3A Li-ion/Li-polymer battery charger for 3cell battery pack
Description:
Universal Smart Charger for 11.1 V Li-ion/Li-polymer battery packs
CCCV charging mode,
Built in IC to cut off power automatically when battery is fully charged at 12.6V
Cut-off Voltage 12.6V
Charging current 300mA (0.3A)
Led indicate charging status:
Red---in charging;
Green: No battery is connected
Green---fully charged
Safety protection
MCU control charging process to avoid over charge
Short circuit protection
Battery reverse connection protection
Over temperature protection.
Input:100-240Vac 50-60Hz 1.0A
Output:12.6Vdc
charging current:300mA
Dimension: 3.5\'\' L x 1.5\'\' W x 1\" H.3.5\'\' (89mm)L x 1.5\'\'(38mm) W x 1\"(25mm) H
Weight:180g
Charging time = (1.5 x mAh rate of battery) / 300 mA
Applications:
Medical care system, Li-ion/Li-polymer battery packs, Airsoft gun, RC Car, RC toy, RC Plane, E-bike, RC Air plane, Diving light, Bicycle, Power? tool, Halogen bike light battery, Bath lift, Pillow lift, Toilet lift, LED Light
Specifications:
|
ITEM |
UNIT |
SPECIFICATION |
REMARK |
|
|
INPUT |
||||
|
01 |
Rating Input Voltage |
V ac |
100~240Vac 50-60Hz |
|
|
02 |
Input voltage range |
V ac |
90~264Vac |
|
|
OUTPUT |
||||
|
03 |
Rating output voltage |
V dc |
12.6V |
|
|
04 |
Suitable for battery cells |
PCS |
3 cells |
Li-ion/Li-polymer battery packs |
|
05 |
Charging current |
A |
0.3A |
|
|
06 |
charge Mode |
CCCV |
Auto switching |
|
|
07 |
charging time |
hour |
?(1.5 x mAh rate of battery) / 300mA |
|
|
08 |
Hold-on time |
ms |
NC |
Input:220Vac Output:Full load |
|
09 |
LED color |
Red:charging Green:finish/idle |
||
|
10 |
Output protect |
- |
OCP&OVP& Polarity error protection |
