Home > Products > VMC Machining Center > 4 Axis Box Guide VMC Machining Center with Highly Rigid Belt Driven Spindle
4 Axis Box Guide VMC Machining Center with Highly Rigid Belt Driven Spindle
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Tapping Engraving CNC VMC Machining Center
-
High Pricision Mold Milling Engraving Machine, 3 Axis Cnc Milling Machines
-
OSKA / SYNTEC CNC Milling Engraving Machine for Aluminum Sole Mold
-
OSKA / SYNTEC CNC Milling Engraving Machine
-
3 Axis Cnc Milling Engraving Machine
-
Dustproof CNC Mold Milling Engraving Machine
Product Details
| Brand Name | Harvest Star | Place of Origin | China | |
| Model Number | HS-1276 |
Product Description
Certification:ISO/CE
Type: CNC Vertical Machining Center, VMC machining center. System: MITSUBISHI / FANUC Controller. Number of axes: 3 / 4 / 5 axis. Table size: 1,400*650 mm. Guideway Type: Box Guide Way. Spindle Type: Belt Driven Spindle. Function: Heavy Cutting, Milling, Drilling and Tapping, High Speed Madding And Engraving. Dimension (L*W*H):3,450x3,000x2,900 mm. Spindle speed: 50-6,000 rpm.
4 Axis Box Guide VMC Machining Center with Highly Rigid Belt Driven Spindle
Specifications:
|
Item |
HS-1276 |
Unit |
|
X Axis Travel |
1,200 |
mm |
|
Y Axis Travel |
700 |
mm |
|
Z Axis Travel |
600 |
mm |
|
Table Size |
1,400x650 |
mm |
|
T-slot Size |
5x18x125 |
mm |
|
Max.Load on Table |
1,800 |
kg |
|
Spindle Taper |
BT-50 |
# |
|
Spindle Speed |
50-6,000 |
rpm |
|
Spindle Nose Table Surface |
110-710/150-750 |
mm |
|
Spindle Center to Column Surface |
725 |
mm |
|
Spindle Power |
15(20) |
kw(HP) |
|
Spindle Torque |
95.5 |
N.M |
|
X/Y Axis Rapid Traverse |
15,000 |
mm/min |
|
Z Axis Rapid Traverse |
12,000 |
mm/min |
|
X,Y,Z Feed Rate of Cutting |
1-6,000 |
mm/min |
|
3 Axis Motor Power |
3/3/3 |
kw |
|
Max. Tool Weight |
15 |
kg |
|
MAX. Tool Length |
350 |
mm |
|
Max. Tool Diameter |
112/200 |
mm |
|
Positioning Precision |
±0.005/300 |
mm |
|
Repeating Positioning Precision |
±0.003/300 |
mm |
|
Controller |
MITSUBISHI / FANUC / SIEMENS | ? |
|
Coolant Tank Capacity |
350 |
L |
|
Pneumatic Source Requirement |
6-7 |
kg/cm2 |
|
Power Requirement |
35 |
KVA |
|
Machine Weight |
12,000 |
kg |
|
Machine Size |
3,450x3,000x2,900 |
mm |
Options available:
1. MITSUBISHI / FANUC Controller
2. 24-tool changer
3. Chip conveyor scre
