Automatic Feeding Traveling Head Shoe Cutting Machine , 46# Hydraulic Oil

YL-898Q Automatic Feeding Traveling Head Cutting Machine

?

Quick Detail:

Automatic Feeding Traveling Head Shoe Cutting Machine , 46# Hydraulic Oil

?

Description:

YL-898Q Automatic Feeding Traveling Head Cutting Machine has various working modes such as inching, manual and automatic etc. It is suitable for all kinds of materials, such as shoes uppers, handbags, leather, sole and other leather goods with multi-layers.

Technical Features:

1. The auto feeding traveling head cutting machine is applicable to continuous cutting operation of nonmetal rolled materials of same specifications and large batches by die cutter. For example, used in such industries as football, volleyball, tennis and medicine etc.

2. the servo motor is adopted to control the horizontal movement of cutting head, and the multilayer materials are clamped by the cylinder for stepping feeding. The machine can automatically complete the cutting of materials and the displacement distance of cutting head and feeding length can be accurately set, which has solved the problem of inaccurate feeding and layering length of multilayer materials.

3.? The machine has various working modes such as inching, manual and automatic etc. modes. The workers need only to pick up the finished materials, with labor intensity reduced and work efficiency enhanced.

4. the machine has cutting modes of stagger, stagger blade reducing and die cutter rotation etc., which can save 10%~15% of raw materials.

5. As the machine is controlled by microcomputer with high automation degree, only? one worker is required for the whole machine, so that the production efficiency can? be enhanced for 3-5 times and the power can be almost 1/3 saved.

6. with special setting mechanism, and in conjunction with die cutter and cutting depth setting, the travel adjustment is simple and accurate.

7. Products of special specifications can be customized, Optional cutting board micro-movement device.

Specifications:

Application:

This automatic feeding traveling head cutting machine applies to the shaping and the cutting of one layer or several layers of the materials such as leather, rubber, canvas, nylon, cardboard.

Competitive Advantage:

1.???? Italian Technology
