Stainless Steel Z Bracket/Z Anchor/Marble Fixing Systems/Cladding Fixing Systems

INOX AISI304 Marble fixing systems,Cladding Fixing System, Stone Anchorage System, Dry-Hang Fixing

This Cladding Fixing Systems contains Ext Arm(Flat Head Bolt), Flange Pin, Hex Nut, Serrated Washer, Wedge Anchor and Z Anchor. The material is INOX AISI304-A2/AISI316-A4 Stainles Steel Z Anchor/Cladding Fixing /Marble Bracket/Cladding Clamp/Marble Clamp/Strut Fitting/Marble Fixing/Stone Fixing/Beam Clamp Direct fixing in to concrete walls with expansion bolts. Indirect fixing on to sub channel system with hex bolts Suitable for concrete walls. Anchors are fixed directly on to concrete walls with expansion bolts. 1. Recommended projection size between 45 mm to 135 mm and loads up to 800N.

2. In horizontal joint installation slabs are pinned on the bottom and upper sides. Anchors act as load bearing carrying half the weight of the slabs above. Anchors also act as restraint holding the slabs below and restraining against wind suction and pressure. 3. In vertical joints installation slabs are pinned at the left and right sides. Anchors on the bottom are load-bearing anchors carrying the whole weight of the slab. Half the weight of the slab on the left and half the weight of the slab on the right. Anchors on the top are restraint anchors holding the slabs and restraining against wind suction and pressure. 4. Three - dimensional adjustability allows quick and easy installation.
