GARDNER DENVER PZ-10, PZ-11-API-7 FLUID END MODULE & ACCESSORIES

ITEM      OEMPART     MISSION PART     DESCRIPTION       QTY

#     #     #     RETURNTO GARDNER DENVER INDEX

              FEMPZ1011CA     FLUID END MODULE COMPLETE ASSY   (INCLUDES ITEMS 1-24)   3

1     202PZL029B FEMPZ1011  FLUIDEND MODULE STUDDED   (INCLUDES 1-8 &24)   3

02   201PZL110   PZ1011LCS   STUD,FRAME & LINER CLAMP LONG     24

03   205PZL110   PZ1011GPFS STUD,SHORT       24

04   50B36    PZ789LCSN   NUT,FRAME & LINER CLAMP STUD 72

05   204PZL110   PZ1011TRS    STUD      72

06   50B34    PZ789TRSN   NUT(FOR ABOVE)       72

07   202PZL110   PZ789DMS    STUD,DISCHARGE MANIFOLD  12

08   50B34    PZ789TRSN   NUT(FOR ABOVE STUD) (SAME AS ITEM 6)   12

10   200PL387     PZ1011FLG   RING,VALVE COVER THREADED      6

11   204PZL715   07916780     GASKET,VALVE COVER       6

12   2007674       PZ789VGI     BUSHING,VALVE GUIDE    6

13   200PZL147   PZ1011VC     COVER,VALVE      6

14   200PZL587   PZ1011CAP   CAP,VALVE COVER LOCK   6

15   2011701       PZ789PL       PLATE,RETAINER  3

16   200PZL483   PZ1011LVG  GUIDE,VALVE SUCTION     3

17   95W2     PZLVGAWASHER   WASHER, LOCK 1/2" 316SS      6

18   655EE065      PZLVGABOLT SCREW1/2" x 1 3/4" 316SS HX HD C/S   6

19   25AL35  077070074701    GASKET,DISCHARGE MANIFOLD     3

20   25G41    07923283     GASKET,SUCTION MANIFOLD  3

21   200PZL455   PZ1011LC     CLAMP,LINER      3

22   200PZL483A PZ1011LVGA ASSY.,LOWER VALVE GUIDE ( INCLUDES ITEMS 12, 16-19.)       3

23                 CAPSCREW,SUCTION MANIFOLD

              07924509     MODULE SEAL KIT:  (KIT INCLUDES CYLINDER  HEAD, VALVE COVER GASKET, LINER GASKET,DISCHARGE MANIFOLD GASKET, SUCTION MANIFOLD GASKET)     3
