SMD 3528 P12 Led display No gap connnection

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Charming		Place of Origin	China
Model Number	COL-PA.012.5002

P12 Indoor Display

led indoor display P12

1) 3528 SMD 3 in 1 LED
2) big view angle, easy maintaining, easy install

3) beautiful color, high brightness

4) fixed cabinet or hanging cabinet

5) steel iron and aluminum alloy material

6) perfect for screen in club and indoor decoration

Type No.	COL-PA.012.5002
Pixel Pitch (mm)	12
LED standard	SMD ,3 in 1
Pixel composition	1R* 1G* 1B
Pixel density (dot/m2)	6944
Dimensions (mm)	384*192
Module resolution (L*W)	32*16
Scan mode	1/8
Brightness (CD/m2)	1400
Minimum viewing distance (M)	12
cabinet size (L*W)(mm)	1152*768
Cabinet material	Aluminum alloy/ Iron
Cabinet weight	24KG/30KG
Power consumption	Max. 868 W/m2 Average: 450W/m2
Display color	16.7 Million
Protection Level	IP31
View angle	130 degree
Grey level	409 6level
Working temperature	-20 °C ~+60 °C
Working humidity	10%~90% RH
Life span	30,000 hours
Working voltage	AC 170~240 V / (110V) ±15% , 47~63 HZ
Signal transfer	Lan cable
Control system	Computer control system / SD card system
System platform	Windows 98 or above
Effective Control Distance	≤ 100 M (by LAN) , ≥ 100 M (by fiber optic with multi-module or single module
Video sources available	DVD, VCD, VCR, TV, camera with PAL/NSTC
