Home > Products > Cast Iron Ball Valve > Cast Iron 2PC PN10 GG40 BS5159 0.4~0.7Mpa Air Seal Pressure Flange Grey Cast Iron Ball Valve
Cast Iron 2PC PN10 GG40 BS5159 0.4~0.7Mpa Air Seal Pressure Flange Grey Cast Iron Ball Valve
US$ 10 - 1000 /
/ Piece
1 Piece(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
DIN3357 PTFE Seat Ball Valve / GG25 Carbon Steel Nut DIN2533 Flange PN16 Cast Iron Ball Valve
-
BS5159 50mm Flange Ball Valve / 0.4~0.7Mpa Air Seal Pressure GG25 PN16 Cast Iron Ball Valve With BS4
-
DN15-DN250 BS PN16, DIN, JIS GG25 BS4504 Flange Ball Valve / 15mm-300mm Manual Cast Iron Ball Valve
-
A126B BS PN16, DIN, JIS GG25 BS4504 Flange Ball Valve / 15mm-300mm Manual Cast Iron Ball Valve
-
A126B Ball Valve / A126B Manual ISO,CE,DQS Cast Iron Ball Valve With 125LB Pressure
-
ANSI 50mm ANSI 125LB 125LB Grey Cast Iron Ball Valve / Stainless Steel Ball Valves
Product Details
| Brand Name | EVB | Place of Origin | China | |
| Model Number | BV-018-A |
Product Description
Cast Iron 2PC PN10 GG40 BS5159 0.4~0.7Mpa Air Seal Pressure Flange Grey Cast Iron Ball Valve
1.Material:GG40
2.Trade Term:FOB
3.Certification:ISO,CE,DQS
4.Pressure:PN10
5.ball valve,Factroy Price!
| Application | |||||||||||
| Face to face is according to BS5159 | |||||||||||
| Flange connection is according to BS4504 | |||||||||||
| Nominal Pressure 1.6Mpa | |||||||||||
| Test Pressure Shell 2.4Mpa | |||||||||||
| Air Seal Pressure 0.4~0.7Mpa | |||||||||||
| ? | |||||||||||
| Main Parts and Materials | |||||||||||
| Number | Part Name | Material | |||||||||
| 1 | Body | Grey Cast Iron(GG25 or GGG40) | |||||||||
| 2 | Bonnet | Grey Cast Iron(GG25 or GGG40) | |||||||||
| 3 | Ball | SS 304 | |||||||||
| 4 | Seat | PTFE | |||||||||
| 5 | Gastket | PTFE | |||||||||
| 6 | Stem | SS 304 | |||||||||
| 7 | Stem Packing | PTFE | |||||||||
| 8 | Stop Collar | Carbon Steel | |||||||||
| 9 | Gland Flange | Grey Cast Iron(GG25 or GGG40) | |||||||||
| 10 | Lever | GGG40 | |||||||||
| ? | |||||||||||
| Main Dimensions | |||||||||||
| DN | 15 | 20 | 32 | 40 | 50 | 65 | 80 | 100 | 150 | 200 | 250 |
| L | 108 | 117 | 140 | 165 | 203 | 222 | 241 | 305 | 394 | 457 | 533 |
| C | 65 | 75 | 100 | 110 | 125 | 145 | 160 | 180 | 240 | 295 | 355 |
| D | 95 | 105 | 140 | 150 | 165 | 185 | 200 | 220 | 285 | 340 | 405 |
