Product Details
| Brand Name | XCMG | Place of Origin | China | |
| Model Number | XZJ5120ZLJ |
Product Description
Certification:CE
6550*2480*3044nnn Garbage Dump Truck / Dumping trucks, XZJ5120ZLJ for collect and forward the refuse
Description:
Dumping trucks are special purpose vehicles to collect and forward the refuse conveniently, avoid any leakage? pollute? the? road? will? transport, ideally utilities for city sanitation.? They? are? two types of the carriages,? top opening carriage and sealed carriage. top opening carriage garbage trucks are mainly designed for bulk refuse loading, also can support the large vertical compressor. Sealed carriage garbage trucks are mainly for support small-middle size compressor, as forward vehicles, very important ring of refuse treatment system.
Applications:
?Dumping trucks are special purpose vehicles to collect and forward the refuse conveniently, avoid any leakage? pollute? the? road? will? transport, ideally utilities for city sanitation.?
Specifications:
|
Vehicle Model |
XZJ5120ZLJ |
|
Chassis model |
DFL1120BI |
|
Maximum total mass |
12490kg |
|
Kerb mass |
6500kg |
|
Rated pay load |
5795kg |
|
Carriage volume |
13.6L |
|
Tilt angle |
≥48° |
|
Max. pressure of hydraulic system |
18Mpa |
|
Size(length×width×height) |
6550*2480*3044nnn |
|
Vheelbase |
3800mm |
|
Front overhang / rear overhang |
1430/1320mm |
|
Approach angle |
20/21° |
|
dump time |
≤60s |
Competitive Advantage:
Use the technology and processing experience of internal & external for reference , designing according to china\' actual conditions,? is an highly adapta bility machine. Select and use famous brand chassis, meet emission standards, ?saving energy and? miore economic. ?? Adopt close body, sealed backdoor and big volume sewage tank to avoid leakage and pollution on the way. Adopt dumping type of unloading garbage, simple in structure and dumping garbage in rapid speed. Adopt air controlled + hand operated operation type to control container backdoor and overturning body, that reduce the intensity of labour and improve working environment. Adopt explosion valve,? hydraulic lock and safety rod to ensure that the operation is safely and reliable.Contact Us
