torsion servo E210 controller CNC press brake

Brand Name	hudong		Place of Origin	China
Model Number	WD67K-100T/3200

torsion servo E210 controller CNC press  brake
model 100T/3200
Nominal force 1000 kN
Bending Max thickness 4mm
Bending length 3200 mm
Poles distance 2600mm
Throat depth 300mm
Slider travel 130mm
Max Opening height 380mm
Slide up and down speed 80mm/s
Slider to return speed 50mm/s
Slider work speed 6.5mm/s
power 7.5KW
Backgauge X axes travel 600mm
Dimension 3400X1450×2350
weight 6.6T
1. A hydraulic valve: ATOS group.
2. Fuel tank: seals tripod base, rolling technology, with high wear resistance.
3 rack various components of a steel plate welded structure, tempering and vibration aging treatment, to eliminate the deformation caused by the welding stress and work stress, to ensure the accuracy of the machine to maintain.
4. Fuselage overall structure, easy to transport, ease of processing, to ensure that the machine precision of the machine.
5. Important parts of the body, slider, etc. are analyzed using ANSYS finite element analysis software to ensure the reliability of the machine.
6. Both ends of the cylinder placed on both sides of the column, direct drive slider; machine structure is simple and good rigidity.
The slider is forced to synchronize the torsion bar, and can withstand a certain degree of partial load.
7 on the mold is equipped with precision compensation agencies, the workpiece can obtain high bending accuracy
8.Backgauge slide stroke are displayed on the monitor.
9. This system can be realized slider rapid decline, slow decline, Work Speeds bending, quick return, and up down the process of slider emergency stop such action.
10. Electrical controls are centralized and reliable, as follows:
Power facilities are located within the body, through the control panel button operation to control and achieve.
Has a foot switch, the bending action through its direct, convenient and quick.
Motor overload and short circuit protection, through the air switch.
11. Mold material: 60 steel.
