Home > Products > Oil Temperature Controller > 3N-380-50HZ MTC Oil Temperature Controller for Laminating Presses / Molding Presses CE, ISO9001:2000
3N-380-50HZ MTC Oil Temperature Controller for Laminating Presses / Molding Presses CE, ISO9001:2000
- 0 Metric Ton / Metric Tons per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
High Temp 24KW Oil Temperature Controller AOS-30-24 Temperature Control from 25C to 180 C
-
180 Industrial Mold Oil Temperature Controller Units for Rubber and Plastic / Stamping Machine
-
High - Voltage Explosion - Proof OEM Indirect Cooling Industrial Plastic Oil Temperature Controller
-
Mold Circulation Oil Temperature Controller Unit 180 For Etching Machine / Paper Bag Machine
-
3N-380-50HZ 36KW Heating Power AOS-50-36 Oil Temperature Controller For Woodworking Machinery
-
25C to 300 C Oil Circulation Mold Temperature Control Machine AEOT-300-360 for FRP Equipment
Product Details
| Brand Name | AODE | Place of Origin | China | |
| Model Number | AOS-50-45 |
Product Description
Certification:CE & ISO9001:2000
??
3N-380-50HZ MTC Oil Temperature Controller for Laminating Presses / Molding Presses CE, ISO9001:2000
AOS-50-45 Mold Temperature Control Units(MTC) are used to preheat a process to the desired operating temperature by engaging the unit\'s electric immersion heater and recirculating the oil in the system. Oil type MTC circulate high temperature heat transfer fluid through the process application for temperature control. AOS series MTC offer the range of temperature control from?25°C?to?180 °C.
SAFETY PROTECTIONS:
No-fuse breaker for the overcurrent phenomenon of general power supply. Motor reversion protection and indicator light up. Cooling water lacking protection and indicator light up. Circulating pump overload protection and indicator light up. BY-PASS pressure release loop for hot oil. Phase failure protection. High-voltage explosion-proof device. Anomaly explosion-proof buzzer. Prevent dry combustion device, discharge scale deposit protection. No-voltage exhaust protection system.SPECIFICATION DETAILS:
|
No. |
Part |
Specification |
Data |
|
1 |
model |
AOS-50-45 |
|
|
2 |
power supply |
3N-380-50HZ |
|
|
3 |
Hot medium |
oil |
|
|
4 |
control mode |
PC board Self - optimized microprocessor |
|
|
5 |
accuracy of temp. control |
PID±1℃ |
|
|
6 |
Max. temperature |
180℃ |
|
|
7 |
Min. temperature |
25℃ |
|
|
8 |
heating power |
45KW(adjustable) |
|
|
9 |
heat exchange area |
0.1M2 |
|
|
10 |
Pump |
model |
RGP-50-200 |
|
power |
3.75KW |
||
|
lift |
30M |
||
|
flow |
250L/min |
||
|
11 |
heating method |
Direct heating(Indirect cooling) |
|
|
12 |
Pipeline |
hot medium inlet/outlet |
DN32(adjustable) |
|
cooling water inlet/outlet |
DN15(adjustable) |
||
|
drain oil port |
DN15(adjustable) |
||
|
13 |
Temp. Controller |
model |
P6100(WEST) |
|
modulating action |
Dual PID control of heating & cooling |
||
|
Temp. interaction stick |
K- thermocouple |
||
|
display status |
Respectively display set point & real point |
||
|
output select |
SSR output |
||
|
14 |
|
