wall-mounted quakeproof Fiber Optic Splice Closure (FOSC-GJS03B) ageing resistance

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

Wangpo

Place of Origin

China

Product Description

Delivery Time:7 DAYS
Certification:Rohs

wall-mounted quakeproof Fiber Optic Splice Closure (FOSC-GJS03B) ageing resistance

?

The optic fiber splice closures (fiber enclosures)are widely apply for the connecting of optical cable.?
?

1. The material of FOSC body:ageing resistance & ultraviolet radiation resistance
2. Base-to-dome seals on FOSC are mechanical and heat-shrinkable for ease of installation and reentry.
3. Compatible with most cable types(single fiber or ribbon), and cable constructions(loose tube, central core, slotted core, modular). And the product can be used in any environment (aerial, buried, handhole, manhole)and in many applications(tap-off, expressed, branch, and repair)
4. No special tools are needed to open the closure, and it can be opened and used repeatedly.

4 small holes(dia.2cm) +1 oval hole(The major axis of the oval hole(inside wall) is 6cm,and the shorter axis of the oval hole is 4cm)

The main models include:
GJS03B -JF96?? single fiber min:?? 24 cores/max:96 cores
GJS03B -JF144 single fiber max:144 cores

Technical Parameter:
1. Working Temperature: -40 degrees centigrade~+70 degrees centigrade
2. Atmospheric Pressure: 70~150Kpa
3. Axial Tension: >2000N/1min
4. Stretching Resistance: 2500N/10 square centimetre(1min)
5. Insulation resistance: >2*104MΩ
6. Voltage Strength: 15KV/1min, no arcover or breakdown
7. Pressure in the water: 50m/72hours
8. Splice tray with optical taking-in radius≥40mm. Low optical loss
