GSM-B10 850 / 900 / 1800 / 1900MHz Band GSM Elderly Guarder Alarm System With 3 Family Button and SO

Brand Name	UVI		Place of Origin	China
Model Number	GSM-B10

Delivery Time:3~5days
Certification:CE

GSM-B10 850 / 900 / 1800 / 1900MHz Band GSM Elderly Guarder Alarm System with 3 Family Button and SOS

GSM-B10 gsm elderly alarm system, Quad-band, Plastic round cover, compact size,Elderly security, 3 family button and SOS button

The B10 GSM Elderly Guarder is a very innovative concept of GSM Panic Alarm, GSM Emergency Call System and GSM Medical Alarm System. Only press the button to ask for help, and press the Familiarity Number buttons to talk to the familiarities.The GSM Elderly Guarder B10 is a very useful product. We’re based on the background of many elderly people living alone to design it. This is the first product special for safeguard and medical and including spiritual care for the elderly in the worldwide . It can be used for monitoring aid, elderly person and all theemergency help through GSM Network with our innovative concepts.The GSM Elderly Guarder with user friendly design idea, all operations and settings can be programmed by PC Configurator or remotely by SMS commands!.If you want, The control panel can be reset to the factory default by following operation: Switch off the Control Panel, then press the Reset Button (S1, nearby the SIMCard Socket), Switch on the Control Panel, about 3Seconds later, the control panel will make “Di Di Di” 3 sounds, then loose the reset button, m eans the reset operation successful.

Applications:

Used for monitoring aid, elderly person and all the emergency help through GSM Network

Specifications:

DC Power supply	Standard adapter: DC9V/1A
GSM Frequency	Quad-band(850/900/1800/1900Mhz)
SIM Card	Supporting 3V SIM Card
GSM Antenna	50 Ω SMA Antenna interface, internal
Wireless Frequency	433.92Mhz
Worn Panic Button Transmission Dist	60meters in open air
Wireless Detectors Transmission Dist.	100meters in open air
Acceptable Max. Worn Panic Button	315/433MHZ
Wireless sensor permission quantity:	3Pcs(If not use 24-Hour zones then is 6Pcs)
Acceptable Max. Wireless Detectors	7Pcs(4 for watchdog zones, 3 for 24-Hour zones, if not use Worn Panic Button and Wireless Panic Button then is 6Pcs for 24 -Hour Zones )
Backup Battery	3.7V 900mAh Rechargeable Lithium Battery
Temperature range	?-20-+60 °C

Competitive Advantage:

Quad-Band (850/900/1800/1900Mhz) ensure it can work in the worldwi de; Big Red Panic Button or Waterproof Worn Panic Button to Ask For Emergency Help;

When the aid, elderly, children and disab led need help, they can press the Big Red Button, or press Waterproof Worn Panic Button or any other Wireless Panic Button, the GSM Elderly Guarder will automatic send SMS Alert to 3 Cell phone numbers and dial 5 assigned numbers then automatically create two way voice communications.

4 Wireless Watchdog Zones to Monitoring Activities of Daily Living; The GSM Elderly Guarder with 4 wireless watchdog zones, it is very useful to monitoring the elderly or aid has pass through special space in the pre-set time, b ecause of normally a person should pass through these places. E.g.: Went out the bedroom, went to the kitchen, went to th e dining room, and went to the washing room. 3 Wireless 24Hours Zones to Monitoring Living Environment; The GSM Elderly Guarder supports 3 wireless 24Hours Zones, special for smoke detector, gas leakage detector and water leakage detectors. 4 Timers for Reminding Elderly to Take Medicine on Time; The GSM Elderly Guarder accepts 4 timers, special for alerting the elderly to take the medicine on time or others Familiarity Numbers For Easy to Dial 3 Telephone Numbers; Familiarity Number is also a very useful function for Two-way voice communication, once press any one of the Familiarity Number button, the system will create two-way voice communication with the assigned number. So the elderly or
