Beer bottling monoblock machine

Beer bottling triblock machine combines the bottle washing, filling and capping on one machine.

Beer tank liquid level control probe, regulate the beer level sleeplessly. Steady liquid level confirms steady filling.

Life the filling nozzle by cylinder instead of traditional spring. Filling nozzle press against the bottle mouth completely. Protect the bottles.

Twice pre-evacuation. Keeps the original beer flavor, good taste.

Washing: The lifting device adjusts according to the bottle height.

         Little water consumption collects water for reuse.

Filling: 1. Pre-evacuation button: this button controls the bottle pre-evacuation work before beer filling.

2. Air-discharge button: this button controls the air discharge after beer filling finished.

3. When there is no bottle in the filling valve, there is button will not order the pre-evacuation button to evacuation. That is, this button control the process of “no bottle, no evacuation work” to keep the high evacuation rate when there is bottles in the filling valve.

     4. Beer distributor: When the beer is filled into the bottle, beer will pass this distributor so that beer flows from the bottle inside wall to reduce foam.

Capping: Most advanced technology, seal the bottle excellently.

Fill cap as soon as the bottle is transmitted to the capping position.

        Infrstrd ray inspect the cap avoid no caps.

Beer tank: Adopted the special device to keep well the stability of liquid level and CO2 pressure. In addition, in the small factory the open and close valves of this machine are mechanical control. But, our open and close valve are all controlled by cylinder(AIRTAC), which keep the work stable and make the machine work long life. Meanwhile, our machine has the high-pressure foaming device. You know, before capping, the filled bottle will run a distance opening the mouth. Once the bottle is finished fill, this foaming device will arouse the foam in the top of the beer in the bottle by the aseptic water to keep from germs into beer.

Control cabinet: the control components, PLC and wires are the most famous brand such as Siemens, Mitsubishi.
