high efficiency flexible steel scaffold-plywood doka table formwork system for concrete construction

????????????????????????????????????????????????????????????????????formwork?scaffolding?manufacturer

Introduction

We?are?manufacturer?specialized?in?scaffolding&formwork?materials.?Our?best-selling?products?are?slab?

formwork?system(Patent?No:ZL200420091863.6).?It\'s?adjustable?system,?very?time-saving?and?labor-saving.?

They?replaced?timbers,steel?pipe&couplers.Wasting?of?timbers?and?couplers?can?be?avoided.?Moreover,this

?system?can?quicken?construction?period?and?improve?quality?of?concrete?casting.?

1,?Material?

It?is?made?of?high?pure?cold?steel?,it’s?thickness?is?2?to?2.5?milimeter?,the?characteristics?of?this?kind?of?new?

material?is?corrosion?endurable?,the?flexibility?is?big,?firm?,?hard?to?be?deformed?.

2,Specification??

Main-Beam?The?main?beam?can?adjust?length?within?the?scope?of?1.17m?to?4.39m?at?will,?the?short?spine?is

?used?in?balcony?tolite?and?so?on?.?

B-1?2.68m?to?4.39m

B-2?2.28m?to?3.68m

B-3?1.77m?to?2.88m

B-4?1.17m?to?1.78m???????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????

Sub?Beam?The?sub?beam?has?3?normal?sizes,its?length?as?below:.

1.15m

0.80m

0.40m?

3,Bearing?Capacity:

Its?supporting?pole?can?put?up?3-4?ton?,and?the?zone?between?two?main?beams?can?bear?2-2.5?ton?,?and

?every?sub-beam?can?bear?1?ton?.?Now?the?general?thickness?of?the?concrete?paddled?currently?is?10-15?

centimeters?,and?the?weight?in?the?same?area?is?100-150kg?at?most,?so?the?supporting?strength?is?enough?

for?all?buildings

4,Production?characters?:

??No.1?:?the?narrow?flexible?connection?of?keel?is?not?only?simple?to?manipulate?but?also?firm?and?steady.

??No.2?:?the?telescopic?keel?can?be?regulateed?at?your?will

??No.3:?the?smart?locket?connection?between?vertical?and?keel?is?simple?and?firm?.

??No.4?:?the?horizontal?pole?is?light?and?firm?,the?smart?fastener?is?unique

??No.5:?compared?with?wooden?grider?,it?is?much?preciser?and?firmer

??No.6:?it?can?make?the?construction?site?neat?and?clean?,so?it?helps?to?enhance?the?image?of?the?

corporation and?demonstrate?the?strength?of?the?corporation?.

??No.7:?time-saving?,?material-saving?,?laber-saving,?dependable?safety.

??No.8:?free?timber?,it?can?be?reused?and?help?to?save?energy?resource?and?construction?cost?.so?it?is?

useful

?for?environmental?proection?.

5,Advantage?:

???No.1?:?high?efficiency?,?free?any?technique?,it?is?easy?to?operate?and?raise?the?work?efficiency?by?600%,(

400?square?meters?can?been?finished?within?eight?ours?by?four?people?)

???No.2?:?free?material?,?free?a?nail?wire?timber?tool?,so?it?can?reduce?cost?and?save?much?timber?.

???No.3:?dependable?safety?,?pure?steel?structure?,firm?structure?accessory?firm?connection?safety.

???No.4?:?clean?neat?construction?site,?easy?to?manage?,helpful?to?enhance?the?project?image?and?firmness.

6,Comparision?to?old?scaffolding?system?:

Old?system:??Nowadays,?pipe?&?couplers?together?with?timbers?are?normally?used?as?a?shoring?structure?for?

concrete?casting.?This?system?is?complex?to?operate,?and?takes?much?labors?and?time?.It?also?needs?many?

timbers,?iron?wire,?nails?to?fix.?These?all?caused?a?low?efficiency?and?a?high?cost?and?material-wasting.

DSATSCS?:??In?order?to?overcome?the?disadvantages?,we?finally?invented?the?new-style?kind?of?Digital?Steel

Architecture?Template?Supporting?Combination?Structure?(DSATSCS)?.The??invention?of??DSATSCS??has?

supplied?a?technical?gap?,and?has?won?four?pieces?of?nation?patent?.?DSATSCS?is?easy?to?operate?and

?convenient?to?Install?and?dismantle?.so?it?is?widely-used,?time-saving?and?material-saving?.?What’s?more?,DSATSCS?can?save?a?great?deal?wood?,iron?wire?,nail?and?so?on.

7.?product?range

scaffolding?system,steel?scaffold?parts?an
