Heavy Hammer Crusher/stone Hammer Crusher

FOB Price

US$ 1000 - 10000 / Set

1 Set(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Huahong		Place of Origin	China
Model Number	PCZ series

Product Description

PCZ series Heavy Hammer Crusher

Zhengzhou Huahong Machinery Equipment Co., Ltd. is a leading stone crushing machine and screening equipments manufacturer in China, provides stone crushing machine and screening equipments for various industries such as mining, building material, metallurgy, environmental protection, transportation, chemistry, energy and so on.

Hammer Crusher's Application

Our hammer crusher is mainly applied to stone crusher for construction materials, like road construction, railway and house building and other industries who will use the small stone materials. It is especially suitable to crush limestone, the stone hardness less than 200Mpa and the stone contained more calcium, more or less than 40%.It is designed making use of the inertia of the hammer produced by the motor, to knock the stone into small ones, and it has an impact plate in the back of the crushing cavum to better the materials both in shape and function and make them smaller ones.

Hammer Crusher Durable Parts

1, its alloyed hammer. The hammer is perfectly designed and applied hard alloyed materials to cast the main parts. When the crusher is working, it will gain very large inertia to beat the stone into small ones, and throw them to the impact plate for the second crushing and bettering. Its weight and size can gain very high ratio of crushing and low attrition. So it can crush the limestone as the first process and needn’t the Jaw crusher.

2, its impact plate. We add a plate in the back of the crushing antrum. So it can process the suitable materials just by on crusher. It needn’t the help of impact crusher.

3, its bearing. We applied the fine-steel bearing, and through the hot-oil processing, it is more durable than common bearing. Its super capacity results in its large size mouth. It can crush the stone less than 1100mm for the biggest one.

Main technical parameters:

Type	Rotor Dia×length (mm)	Feed size (mm)	Discharge size (mm)	Capacity (T/h)	Power (KW)	Weight (T)
0806	800×600	≤300-400	0-40	60	55	3.8
0808	800×800	≤400-500	0-50	80-100	75	6.5
1008	1000×800	≤500-650	0-60	100-120	90	8
1010	1000×1000	≤600-750	0-70	120-150	132	11.5
1210	1200×1000	≤650-800	0-70	150-200	185	14
1510	1500×950	≤800	0-80	160-250	200	17.5
1512	1500×1160	≤800	0-80	250-300	250	19
1615	1650×1450	≤900	0-80	300-380	280	28
2015	2000×1500	≤1200	0-80	400-500	400	32
