Double Sided Electronics SMT PCB Boards Design

Welcome To Moko

Electronics PCB Assembly

1.Electronics PCB, PCB Assembly Service
2.UL, SGS, Rohs Certificate
3.Competitive Price+Good Quality
4.OEM Parts, Good after Service

Moko, your single point of contact for all of your raw materials, parts, and pcb assembly, also offers:

- Contract Manufacturing
- Engineering Services
- PCB Design & Assembly
- Product Design
- Prototyping
- Cable and Wire Assemblies
- Plastics and Molds

1.Detailed Specification of PCB Manufacturing

1) Layer:1-30 layer
2) Material:FR-4, CEM-1, CEM-3, Hight TG, FR4 Halogen Free, FR-1, FR-2
3) Board thickness:0.2mm-7mm
4) Max.finished board side:500mm*500mm
5) Min.drilled hole size:0.25mm
6) Min.line width:0.075mm(3mil)
7) Min.line spaceing:0.075mm(3mil)
8) Surface finish/treatment:HALS/HALS lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating
9) Copper thickness:0.5-5.0oz
10) Solder mask color:green/black/white/red/blue/yellow
11) Inner packing:Vacuum packing, Plastic bag
12) Outer packing:Standard carton packing
13) Hole tolerance:PTH:±0.076, NTPH:±0.05
14) Certificate:UL, ISO9001, ISO14001, ROHS, CQC
15) Profiling Punching:Routing, V-CUT, Beveling
16) Assembly Service Providing OEM service to all sorts of printed circuit board assembly

2.Detailed Terms for Pcb Assembly

Technical requirement:

1) Professional Surface-mounting and Through-hole soldering Technology

2) Various sizes like 1206, 0805, 0603 components SMT technology

3) ICT(In Circuit Test), FCT(Functional Circuit Test) technology.

4) PCB Assembly With UL, CE, FCC, Rohs Approval

5) Nitrogen gas reflow soldering technology for SMT.

6) High Standard SMT&Solder Assembly Line

7) High density interconnected board placement technology capacity.

Quote requirement:

1)Gerber file and Bom list

2)Clear pics of pcba or pcba sample for us

3)Test method for PCBA
