OEM LED Perimeter Screen Boards for Sports Stadium Advertising
- T/T L/C D/P D/A
- 7 days
You May Like
-
PH20 Stadium LED Screens Display Boards with 2500 dot /
-
PH10mm Advanced Led Perimeter Stadium LED Screens for View Distance 10m - 100m
-
PH25mm 600 W / sqm Perimeter Advertising Stadium LED Screens for Football Court
-
High Refresh Rate DIP 2R1G1B Virtual Digital Football Stadium LED Screens P16 256x128mm
-
High Color Contrast 2342 PH16mm 1R1G1B 60HZ Safe Outdoor Stadium LED Screens Display
-
P10 Sports Stadium LED Screen for media and advertising , public events
Product Details
| Brand Name | JIAMEI | Place of Origin | China | |
| Model Number | Q-Football Stadium |
Product Description
OEM LED Perimeter Screen Boards for Sports Stadium Advertising
Adopting high brightness LED lamp with wide range led angle that ensure the highest image quantity
The images of LED display are more stable with 2400Hz refresh rate and no vision data miss while transfer by camera for the live show
The module with soft mask and Cabinet Top Round Safeguard are specially designed to protect body hitting.
?The cabinet designed with Epoxy Paint Coated Aluminum, it is so light weight that makes it easy to install and move.
Cabinet Underlay Easy-removable is specially designed to protect water & dirty to Cabinet and Cabinet Back Support Is adjustable so you can adjust the angle to a good value easily
?Function of software divided realizes multi-window display of the complete screen and is able to show images, text, clock and game score and broadcast live show.
|
Item |
PH12(Full-color) |
PH16(Full-color) |
PH20(Full-color) |
|
LED Configuration |
SMD |
DIP |
DIP |
|
Pixel Pitch |
12mm |
16mm |
20mm |
|
Pixel density |
6944dot/㎡ |
3906dot/㎡ |
2500dot/㎡ |
|
Chip Color |
1R1PG1B |
2R1PG1B |
2R1PG1B |
|
Module Size |
192mm*192mm |
256mm*128mm |
320mm*160mm |
|
Cabinet Size |
960mm*768mm |
1024mm*768mm |
1280mm*960mm |
|
Physical Resolution |
160*64 |
64*48 |
64*48 |
|
Dots/Cabinet |
10240dots/cabinet |
3072dots/cabinet |
3072dots/cabinet |
|
Cabinet Weight |
50kg/cabinet |
52kg/cabinet |
75kg/cabinet |
|
Viewing Distance |
>12m |
>16m |
>20m |
|
Horizontal Viewing Angle |
120° |
120° |
120° |
|
Vertical Viewing Angle |
55° |
55° |
55° |
|
Average Power Consumption |
200～400W/㎡ |
500～1000W/㎡ |
350～700W/㎡ |
|
Maximum Power Consumption |
≤800W/㎡ |
≤1500W/㎡ |
≤1100W/㎡ |
|
Displaying Card |
DVI |
DVI |
DVI |
|
Control Method |
Synchronous Control |
Synchronous Control |
Synchronous Control |
|
Drive Device |
Constant Current |
Constant Current |
Constant Current |
|
Drive Method |
1/2 Scan |
static |
static |
|
Frame Rate |
