Fully MPEG2 MPEG4 H.264 High Definition DVB-C STB Receiver, TV Satellite Receivers

Brand Name	Yaojin		Place of Origin	China
Model Number	2219

Delivery Time:35 days after confirm order
Certification:CE/FCC

Fully MPEG2 MPEG4 H.264 High Definition DVB-C STB Receiver, TV Satellite Receivers

DVB-CI,2219,DVB-C receiver ,fully MPEG2/MPEG4/H.264 high definition compliance

Description:

1. Fully SD/HD DVB-C compliant,support full HD 1080p

2.Support SD/HD MPEG2 and MPEG4 AVC H.264

3.Common Interface for various CAS modules

4.Auto and manually scan all available TV and radio channels

5.Powerful and highly effective 7-day EPG function

6.Multi-language menu,subtitle and audio output supported

7.USB 2.0 for PVR,TIMESHIFT,software upgrade and media files playback

8.Support aspect ratio 16:9, 4:3,Pan&Scan,letter box.

9.Support parental local and Teletext

10.Easy to use and attractive menu

11.Support various media files,including music,photo and movie files

Specifications:

Main System

Main Processor????????????????????????????????? ?? MSTAR 7819 chipset

RF Input type?????? ?????????????????????????????? F-type connector

Input impedance???? ????????????????????????????? 75Ω

Min signals level??? ??????????????????????????????? -15 dBmV

Max signals level??? ????????????????? ? ? ? ? ? ?? 20 dBmV

Input Frequency:??? ????????????????? ? ? ? ? ? ?? 47MHz~862MHz

Bandwidth????? ??????????????????????????????????????? 8MHz

Catching Frequency?????? ?????????????????????? ± 150KHz

Input reflection????? ????????????????? ? ? ? ? ? ? ?? ≥8

Decoding ????????????????????????????????????????????? 16,32,64 , 128,256 QAM

Support scope ????????????????????????????????????? 3.6 ～ 6.952 Mbaud

RF Output Type?? ??????????????????????????????? IEC male plug, Loop through

Output impedance????????????????? ? ? ? ? ? ? ?? 75Ω

Audio DECODING

Decoding ????????????????????????? ? ? ? ? ? ? ? ? ? ? MPEG 1/2/3, AC3, AAC

Audio output? ??????????????????????????????????????? Stereo, mono, dual, SPDIF optical digital output

PCM, LPCM, WMA, Mpeg 1/2 layer 1/2

Video DECODING

Transport Stream??????????????????????????????? ?? ISO/IEC 13818-1 MPEG-2, H.264/MPEG-4 AVC

Profile Level????????????????????????????????????? ??? Up to H.264 HD, HP@L4.1, Up to MPEG-2 HD, MP@HL

Aspect Ratio????????????????????????????????????? ?? 16:9 / 4:3 Letter-Box, Pan & Scan

Video Resolution??????????????????????????????? ?? 1920x1080p,1920x1080i, 1280x720p, 720x576p/i

Video Format? ?????????????????????????????????????? PAL,NTSC,SECAM(Option)

Video output standard??? ??????????????????????? Output Scope:1.0±0.05V Vp-p

A/V & Data In/Out

HDMI???????????????????????????????????????????? HD digital display, multi format capable (1080P,1080I, 720P, 480P, 480I)

Y/Pb/Pr???????????????????????????????????????? Analog HD output

SCART ???????????????????????????????????? ?? Video CVBS output, Audio L/R output

SPDIF?????????????????????????????????????????? Digital audio output

USB? ??????????????????????????????????????????? High-Speed USB 2.0 Port

Power Supply

Power input voltage?????? ?????????????? DC 12V, 1A

Power Consumption???????????????????? 10W max

Ambient (Optional)

Dimension????????????????????????????????????? 220(W)×160(D)×38(H)mm

Weight (Net)?????????????????????????????????? 1.5Kg

Shipping Info?????????????????????????????????? 5760sets / 20’ container
